NP420-DN1 | SMC Pneumatic Manifold Controller

Description

The SMC NP420-DN1 is a pneumatic manifold controller designed to manage and control multiple pneumatic valves within an automation system. It serves as a serial interface unit, facilitating communication between a central control system and individual pneumatic components.

Technical Specifications

Information About NP420-DN1

The SMC NP420-DN1 is a pneumatic manifold controller designed to streamline the control and management of multiple pneumatic valves in industrial automation systems. It functions as a serial interface unit, facilitating communication between a central control system (such as a PLC) and pneumatic actuators or valves, enabling efficient and centralized control over complex pneumatic networks.

Key Specifications:

• Model: NP420-DN1
• Type: Pneumatic Manifold Controller / Serial Interface Unit
• Communication Protocol: DeviceNet (DN)
• Voltage Supply: 24 VDC
• Max Current Consumption: ~0.5 A
• Input/Output Capacity:
  • Supports multiple valve stations through a manifold system
  • Capable of controlling several solenoid valves and I/O modules
• Mounting: DIN rail or direct manifold mounting
• Enclosure Rating: IP40 (when properly mounted)
• Operating Temperature: 0°C to 50°C
• Connection Type:
  • DeviceNet communication port
  • Power supply connectors

Key Features:

• DeviceNet Communication:
  The NP420-DN1 uses DeviceNet protocol to interface with PLCs and other control systems, providing a reliable and standardized method for integrating pneumatic valves into complex automation environments.

• Centralized Pneumatic Control:
  The manifold controller manages multiple pneumatic valves from a single interface, reducing wiring complexity and improving system organization.

• Flexible I/O Configuration:
  Supports a variety of valve types and can be expanded to include additional I/O modules for sensors and actuators, enhancing system scalability.

• Compact Design:
  The unit is designed to save space, offering a compact solution that fits directly into existing manifold assemblies or onto DIN rails.

• Error Detection and Diagnostics:
  Built-in diagnostics enable easy troubleshooting and monitoring of valve statuses, helping to reduce downtime and maintenance efforts.

Benefits:

• Simplified Wiring and Installation:
  By consolidating control into a single unit, the NP420-DN1 reduces the need for complex wiring, lowering installation costs and time.

• Improved System Efficiency:
  Real-time control and communication enhance the responsiveness and accuracy of pneumatic operations.

• Flexible Integration:
  Compatible with various SMC valve manifolds and other industrial devices using DeviceNet, making it adaptable to different automation systems.

• Scalability:
  Supports the addition of extra valves and I/O modules, allowing for system expansion as needed.

Applications:

• Factory Automation:
  Used for controlling pneumatic actuators and valves in assembly lines, material handling systems, and packaging machinery.

• Robotics:
  Enables precise control of pneumatic grippers, arms, and end effectors.

• Process Control:
  Manages valves and actuators in fluid handling and other process industries.

• Automotive Manufacturing:
  Controls pneumatic tools, presses, and other automation equipment in automotive assembly lines.

The SMC NP420-DN1 pneumatic manifold controller remains a robust and efficient solution for centralized pneumatic control in legacy automation systems, offering reliable communication and flexible valve management in various industrial applications.
