Product Description P/N: A121224RT
Description
nVent Hoffman A121224RT is a Type 3R screw-cover wiring trough designed to protect and organize electrical wire and cable distribution, junctions, and terminations. It measures 12 × 12 × 24 inches and is constructed from 14-gauge steel with a gray finish for outdoor applications exposed to wet conditions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | nVent Hoffman |
| Category | Industrial Automation |
| Part Number | A121224RT |
| Subcategory | Wiring Troughs |
| Product Type | Type 3R Wiring Trough |
| Series | F40PT |
| Material | Mild Steel |
| Material Gauge | 14 Gauge |
| Height | 12 in (305 mm) |
| Width | 12 in (305 mm) |
| Length | 24 in (610 mm) |
| Finish | Galvanized / Gray |
| Color | ANSI 61 Gray |
| Cover Type | Slip-On Removable Cover |
| NEMA Rating | NEMA Type 3R |
| IP Rating | IP32 |
| Standards | UL 870; cUL / CSA C22.2 No. 26 |
| Weight | 36.7 lb |
Information About A121224RT
The A121224RT is part of the nVent Hoffman Type 3R wiring trough series. Its steel body features seam-free sides, front, and back along with a drip-shield top to provide rain-resistant protection. The removable slip-on cover is secured with screws and the enclosure includes embossed mounting holes on the back. The trough has no knockouts or gasketing and includes a provision for padlocking.
Key Features:
- Type 3R Construction: Provides rain-resistant protection for outdoor wiring applications.
- Steel Housing: Uses 14-gauge steel for the trough body.
- Screw-Cover Design: Features a removable cover secured with screws.
- Drip Shield: Helps protect the enclosure interior from falling water.
- Seam-Free Construction: Provides continuous sides, front, and back surfaces.
- Mounting Provisions: Includes embossed mounting holes on the rear of the trough.
- Padlock Provision: Allows installation of a padlock hasp for additional security.
- No Knockouts: Supplied without factory-installed knockouts for flexible field installation.
The A121224RT delivers the reliability and precision required for outdoor electrical wire routing, junction, and termination applications.
