nVent HOFFMAN N170116G010 SpectraCool N17 1000 BTU Enclosure Air Conditioner
- Regular price
- $1,699.00
- Sale price
- $1,699.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: N170116G010
Description
nVent HOFFMAN N170116G010 is a SpectraCool N17 compact indoor enclosure air conditioner designed to control temperature inside electrical and automation cabinets. It provides approximately 1,000 BTU/hr of cooling capacity, operates from 115 VAC single-phase power, and uses R-134a refrigerant for cooling enclosed industrial equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | nVent HOFFMAN |
| Category | HVAC / Thermal Management |
| Part Number | N170116G010 |
| Subcategory | Enclosure Air Conditioners |
| Product Series | SpectraCool N17 |
| Product Type | Compact Indoor Enclosure Air Conditioner |
| Cooling Capacity | 908/1025 BTU/hr |
| Cooling Output | 266/300 W |
| Input Voltage | 110/115 VAC |
| Frequency | 50/60 Hz |
| Phase | Single Phase |
| Refrigerant | R-134a |
| Full Load Cooling Current | 4.4 A |
| Operating Temperature | 50°F to 125°F (10°C to 52°C) |
| Enclosure Rating | UL Type 12 |
| Internal Loop Protection | IP54 |
| External Loop Protection | IP34 |
| Thermostat | Mechanical, internally mounted |
| Material | Galvanized sheet metal |
| Finish | RAL 7035 light gray, semi-textured powder coat |
| Dimensions | 17.64 × 12.00 × 8.40 in. (448.1 × 304.8 × 213.4 mm) |
| Mounting | Wall or enclosure mount |
| Weight | 50 lb (23 kg) |
Information About N170116G010
The N170116G010 is a narrow-design enclosure air conditioner intended for low-depth cabinets and enclosures up to approximately 12 inches deep. The unit provides nominal cooling performance of 908/1025 BTU/hr and 266/300 W, depending on operating conditions, with a mechanical thermostat located behind the cover. It has a light-gray powder-coated galvanized steel construction and is designed for indoor installation with UL Type 12 enclosure protection. The unit operates on 110/115 VAC, 50/60 Hz, single-phase power and uses R-134a refrigerant.
Key Features:
- Compact Enclosure Cooling: Provides dedicated cooling for electrical, automation, and control cabinets.
- 1,000 BTU/hr Class Capacity: Delivers approximately 908/1025 BTU/hr of nominal cooling performance.
- 115 VAC Operation: Designed for 110/115 VAC, 50/60 Hz, single-phase electrical systems.
- Narrow Cabinet Design: Fits low-depth enclosures and cabinets approximately 12 inches deep.
- R-134a Refrigerant: Uses R-134a refrigerant in the sealed cooling system.
- Mechanical Thermostat: Includes an internally mounted mechanical thermostat for temperature regulation.
- Type 12 Protection: Designed with UL/cUL Type 12 enclosure protection for indoor industrial environments.
- Steel Construction: Uses galvanized sheet-metal construction with a light-gray semi-textured powder-coat finish.
The N170116G010 delivers the reliability and precision required for electrical enclosures, industrial control cabinets, automation systems, and power-distribution equipment.
