NX102-1000 | Omron NX Series PLC Motion Controller with EtherCAT and Ethernet
- Regular price
- $1,432.00
- Sale price
- $1,432.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NX102-1000
Description
The Omron NX102-1000 is a compact machine automation controller designed for integrated sequence, motion, and position control applications. It combines high-speed PLC performance with built-in EtherCAT and Ethernet communications to control machines with precision and reliability. This controller is suited for advanced automation systems requiring synchronized control and industrial networking.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Programmable Logic Controllers |
| Part Number | NX102-1000 |
| Subcategory | PLC CPU Modules |
| Series | NX Series |
| Controller Functionality | Sequence, Motion, and Position Control |
| Primary Task Cycle Time | 1 ms |
| Program Memory | 5 MB |
| Variables Memory | 33.5 MB |
| Max. Synchronous Axes | 2 |
| Max. PTP Axes | 4 |
| Max. Axes (Total) | 15 |
| Communication Ports | EtherCAT Master, EtherNet/IP, Ethernet TCP/IP |
| Max. Expansion Units | 32 NX I/O Units |
| Mounting Type | DIN Rail |
| Weight | 470 g |
Information About NX102-1000
The NX102-1000 is part of Omron’s NX Series machine automation controllers built for modular and scalable control architectures. It supports IEC 61131-3 compliant programming and PLCopen motion function blocks, enabling efficient development of complex control logic. The controller integrates EtherCAT master functionality for real-time motion and I/O synchronization and includes multiple Ethernet ports for industrial communication and OPC UA connectivity. It is commonly used in compact machines, assembly systems, and automated production equipment where precise control and data integration are required.
Key Features:
-
Integrated Motion Control: Supports synchronous and point-to-point axes for coordinated machine movement
-
High-Speed PLC Performance: 1 ms primary task cycle time for fast and deterministic control
-
EtherCAT Master Support: Real-time synchronization of drives, I/O, and field devices
-
Multiple Ethernet Ports: Built-in EtherNet/IP, TCP/IP, and OPC UA server functionality
-
Scalable NX I/O System: Supports up to 32 local NX I/O expansion units
-
IEC 61131-3 Compliance: Standardized programming environment for logic and motion
-
Compact DIN-Rail Design: Space-saving form factor for control panels
The NX102-1000 delivers the reliability and precision required for modern machine automation and motion control systems.
