NX102-9020 | OMRON Controller, DB Connect, 4 Axis, 4 Position Axis, DIN Rail, NXJQ1, NX102 Series
- Regular price
- $2,109.00
- Sale price
- $2,109.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: NX102-9020
Description
Machine Automation Programmable Logic Controller (PLC) CPU Database connection unit with 4 single-axis position control axes - OMRON (NX series - NX102-[][][][] ) - 5MB (Program) + 1.5MB (variables; non-volatile) + 32MB (variables; volatile) memory capacity - DIN rail mounting
Technical Specifications
| Brand | OMRON |
| Category | Controls & Indicators |
| Part Number | NX102-9020 |
| Subcategory | Control |
| Controller functionality | DB connection, OPC-UA, Position control, Sequence control |
| Max. number of synchronous axes | 0 |
| Max. number of PTP axes | 4 |
| Max. number of axes (incl. virtual) | 4 |
| Primary task cycle time | 1 ms |
| Program memory | 5 MB |
| Variables memory | 33.5 MB |
| Communication port(s) | EtherCAT Master, EtherNet/IP, Ethernet TCP/IP |
| Communication option(s) | Serial RS-232C, Serial RS-422, Serial RS-485 |
| Max. number of remote I/O nodes | 64 |
| I/O system | NX I/O Bus |
| Max. number of expansion units | 32 |
| Product Height (unpacked) | 100 mm |
| Product Width (unpacked) | 66 mm |
| Product Depth (unpacked) | 100 mm |
Information About NX102-9020
The OMRON NX102-9020 is a feature-rich controller from the NX102 series, designed for diverse industrial applications. With DB connection, OPC-UA, and advanced motion control capabilities, it supports precise position and sequence control for up to 4 axes. The DIN Rail-mounted controller ensures easy integration into control systems.
This controller boasts a primary task cycle time of 1 ms, delivering high-speed performance. With 5 MB of program memory and 33.5 MB of variables memory, it accommodates complex applications. Communication ports include EtherCAT Master, EtherNet/IP, and Ethernet TCP/IP, providing versatile connectivity options. Serial RS-232C, RS-422, and RS-485 options further enhance communication flexibility.
With a maximum of 64 remote I/O nodes and support for the NX I/O Bus, the NX102-9020 facilitates scalable and efficient system expansion. The compact design, with dimensions of 100mm x 66mm x 100mm, reflects OMRON's commitment to space efficiency and ease of integration, making it an ideal choice for advanced control and automation solutions.
Features
Direct connection to a database, with no special unit, software, or middleware required
PLCopen Function Blocks for Motion Control allow users to create complex programs quickly and easily
Fully conforms to IEC 61131-3 standard programming
DC power supply without battery backup
Up to 32 local NX I/O Units
Up to 12 axes of control via EtherCAT
OPC UA server functionality
Three built-in industrial Ethernet ports
Fast and accurate control by synchronizing all machine devices with the PLC and Motion Engines
The NX1 can utilize information, take safety measures, and control quality while at the same time improving production eciency through high-speed, high-precision control. This contributes to continuous improvement in productivity
Manufacturer information
OMRON Corporation, founded in 1933, is a global leader in automation, sensing, and control technologies. Headquartered in Kyoto, Japan, OMRON delivers innovative solutions for industrial automation, healthcare, electronic components, and social systems, contributing to a safer, efficient, and sustainable world.
