Okuma BLIV-D7575A Dual-Axis Servo Drive Maintenance Unit for CNC Systems
- Regular price
- $2,699.00
- Sale price
- $2,699.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BLIV-D7575A
Description
Okuma BLIV-D7575A is a dual-axis servo drive and maintenance unit designed for motor control in compatible Okuma CNC systems. It supports selectable 15 A, 30 A, 50 A, and 75 A current configurations and incorporates LED indication for operating and diagnostic status monitoring.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Okuma |
| Category | CNC Controls |
| Part Number | BLIV-D7575A |
| Subcategory | Servo Drives |
| Product Type | Servo Drive / Maintenance Unit |
| Axis Count | 2 |
| Supported Currents | 15 A / 30 A / 50 A / 75 A |
| Control Systems | OSP5020 / OSP7000 |
| Supply Phase | 3-Phase AC |
| Input Frequency | 50/60 Hz |
| Status Indication | LED |
| Mounting Holes | 4 × M6 |
| Hole Spacing | 450 × 80 mm |
| Mounting Length | 466 mm |
| Mounting Width | 144 mm |
| Overall Length | 482 mm |
| Overall Width | 160 mm |
| Overall Height | 197 mm |
| Weight | 7 kg (15.43 lb) |
Information About BLIV-D7575A
The BLIV-D7575A is an Okuma two-axis servo drive designed for integration with OSP5020 and OSP7000 CNC control systems. Its architecture supports 15 A, 30 A, 50 A, and 75 A servo configurations, allowing the unit to accommodate multiple compatible drive requirements. The assembly operates with a three-phase AC supply at 50/60 Hz and incorporates LED indicators for local drive-status and maintenance information. Its panel-mount construction uses four M6 mounting holes and is associated with alternate references BL4-D7575A and U0632-0006-001-11.
Key Features:
-
Dual-Axis Control: Provides two servo drive channels for compatible CNC machine-axis applications.
-
Multiple Current Configurations: Supports 15 A, 30 A, 50 A, and 75 A servo configurations.
-
OSP Control Compatibility: Designed for integration with compatible Okuma OSP5020 and OSP7000 control systems.
-
Maintenance Unit Design: Provides servo drive functionality with features supporting system maintenance and diagnostics.
-
LED Indication: Incorporates visual indicators for operating status and diagnostic monitoring.
-
Three-Phase Supply: Designed for operation from a three-phase AC electrical supply.
-
50/60 Hz Operation: Supports standard 50 Hz and 60 Hz input power frequencies.
-
Panel-Mount Construction: Uses four M6 mounting holes with defined mounting dimensions for CNC cabinet installation.
The BLIV-D7575A delivers the reliability and precision required for dual-axis servo motor control and diagnostic monitoring in compatible Okuma CNC systems.
