Okuma VAC5-D22 VAC5 AC Spindle Drive and Amplifier for CNC Systems
- Regular price
- $7,999.00
- Sale price
- $7,999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VAC5-D22
Description
Okuma VAC5-D22 is an AC spindle drive and amplifier designed for spindle motor control in compatible Okuma CNC machine systems. As part of the VAC5 drive platform, it provides a rated capacity of 22 kW and incorporates dedicated encoder, resolver, and optical interface connections for spindle control and feedback.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Okuma |
| Category | CNC Controls |
| Part Number | VAC5-D22 |
| Subcategory | Spindle Drives |
| Product Type | AC Spindle Drive / Spindle Amplifier |
| Series | VAC5 |
| Rated Capacity | 22 kW |
| Interface Type | Optical |
| Encoder Connector | XB-EPG (CN2) |
| Resolver Connector | XB-RES (CN3) |
| Fuse Rating (FR/FS/FT) | 5.0 A |
| Mounting Holes | 4-M8 |
| Mounting Pitch Width | 200 mm |
| Attachment Hole Width | 289 mm |
| Attachment Hole Height | 714 mm |
| Overall Width | 310 mm |
| Overall Height | 750 mm |
| Overall Depth | 290 mm |
| Weight | 41.5 kg (91.49 lb) |
Information About VAC5-D22
The VAC5-D22 is an Okuma VAC5 Series spindle drive unit engineered for AC spindle control in CNC machining equipment. Its construction integrates spindle amplification and control functions within a panel-mount enclosure equipped with four M8 mounting points. Dedicated XB-EPG (CN2) and XB-RES (CN3) connectors provide interfaces for encoder and resolver feedback devices, while an optical interface supports communication within the control architecture. The unit is configured for 22 kW spindle applications and uses 5.0 A FR, FS, and FT fuse protection as part of its electrical design.
Key Features:
-
AC Spindle Control: Provides drive and amplification functions for compatible Okuma CNC spindle motors.
-
22 kW Capacity: Rated for spindle applications requiring a 22 kW drive capacity.
-
VAC5 Drive Platform: Designed as part of the Okuma VAC5 spindle drive and control system.
-
Encoder Interface: Includes an XB-EPG connector at CN2 for compatible encoder feedback.
-
Resolver Interface: Provides an XB-RES connector at CN3 for resolver feedback connections.
-
Optical Interface: Incorporates an optical interface for communication within compatible control configurations.
-
Fuse Protection: Uses 5.0 A FR, FS, and FT fuse ratings for electrical circuit protection.
-
Panel Installation: Uses four M8 mounting holes with defined mounting dimensions for secure cabinet installation.
The VAC5-D22 delivers the reliability and precision required for AC spindle motor control and feedback management in compatible CNC machining systems.
