Omron CJ1W-MD563 Digital I/O Module 32 TTL Inputs 32 TTL Outputs 5VDC CJ PLC Expansion
- Regular price
- $1,347.00
- Sale price
- $1,347.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CJ1W-MD563
Description
The Omron CJ1W-MD563 is a digital I/O module designed for high-density signal interfacing in CJ-series PLC automation systems. It provides 32 TTL digital inputs and 32 TTL digital outputs operating at 5 VDC for precise logic-level control. This module is intended for applications requiring fast and reliable data exchange between PLCs and electronic control circuits.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation and Controls |
| Part Number | CJ1W-MD563 |
| Subcategory | PLC Modules |
| Series | CJ1W |
| Module Type | Digital I/O Module |
| I/O System | CJ I/O Bus |
| Number of Inputs | 32 Digital Inputs |
| Input Type | TTL |
| Input Voltage Range | 4.5–5.5 VDC |
| Number of Outputs | 32 Digital Outputs |
| Output Type | TTL |
| Output Voltage Range | 4.5–5.5 VDC |
| Output Current | 35 mA per Output |
| Connection Type | MIL Connector (Plug Not Included) |
| Number of Connectors | 2 |
| ON/OFF Delay | 0–32 ms |
| Dimensions | 90 × 31 × 83.6 mm |
| Weight | 110 g |
Information About CJ1W-MD563
The CJ1W-MD563 is a basic I/O expansion unit from Omron’s CJ1W series, designed for use on the CJ I/O bus. It combines both input and output functionality in a single module, enabling efficient signal handling within compact control systems. The module supports TTL-level signals with a voltage range of 4.5 to 5.5 VDC, making it suitable for interfacing with electronic devices and logic circuits. It features MIL-type connectors for secure connections and is designed for installation within industrial control panels using standard PLC mounting configurations.
Key Features:
-
32 TTL digital inputs: Enables high-density input signal acquisition from electronic devices and logic circuits.
-
32 TTL digital outputs: Provides reliable output control for low-voltage logic-level applications.
-
5 VDC TTL operation: Supports precise control and compatibility with TTL-based systems.
-
CJ I/O bus compatibility: Designed for seamless integration with Omron CJ-series PLC systems.
-
MIL connector interface: Ensures secure and stable connections for I/O wiring.
-
Adjustable ON/OFF delay: Supports configurable response timing from 0 to 32 ms.
-
Compact combined I/O design: Reduces panel space by integrating inputs and outputs in one module.
-
DIN rail mounting compatibility: Suitable for installation in industrial control enclosures.
The CJ1W-MD563 delivers the reliability and precision required for high-speed TTL signal interfacing in industrial PLC automation systems.
