CJ1W-NC213 | Omron 2-Axis Position Control Module with 500 kHz Pulse Output
- Regular price
- $244.00
- Sale price
- $244.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CJ1W-NC213
Description
The Omron CJ1W-NC213 Position Control Module is a compact 2-axis motion control unit designed for precise positioning within CJ1-series PLC systems. It provides high-speed pulse output up to 500 kHz, enabling accurate control of servo and stepper drives. This module is suited for synchronized motion and positioning tasks in industrial automation applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation |
| Part Number | CJ1W-NC213 |
| Subcategory | Position Control Modules |
| Product Line | CJ1 |
| Product Type | Position Control Module |
| Number of Axes | 2 Axes |
| Output Type | NPN Open Collector Pulse Output |
| Line Driver | RS-422 Compatible |
| Maximum Pulse Frequency | 500 kHz |
| Speed Range | 1 pps to 500 kpps |
| Acceleration/Deceleration Time | 0 to 250 seconds |
| PCU Power Supply Voltage | 5 V DC |
| External Power Supply Voltage | 5/24 V DC |
| Internal Current Consumption | 250 mA at 5 V DC |
| Operating Temperature | 0°C to 55°C |
| Dimensions (H × W × D) | 90 × 31 × 65 mm |
| Weight | 0.13 lbs (0.06 kg) |
Information About CJ1W-NC213
The CJ1W-NC213 is part of Omron’s CJ1 motion control expansion lineup, engineered to integrate directly with CJ1 PLC CPUs. It supports two-axis positioning with both direct operation and memory-based operation modes, allowing flexible control strategies. The module features NPN open collector pulse string outputs and RS-422 line driver compatibility to ensure reliable signal transmission to connected drives. Designed for stable operation in industrial environments, it operates within a wide speed and acceleration range while maintaining low internal current consumption.
Key Features:
- Two-Axis Control Capability: Enables independent or coordinated positioning control of two motion axes.
- High-Speed Pulse Output: Supports pulse output frequencies up to 500 kHz for precise motion execution.
- Flexible Positioning Modes: Allows both direct operation and memory operation for versatile motion programming.
- NPN Open Collector Output: Provides compatibility with a wide range of servo and stepper motor drivers.
- RS-422 Line Driver Support: Ensures stable, noise-resistant pulse signal transmission.
- Wide Speed Range: Operates from 1 pps to 500 kpps to accommodate fine positioning and high-speed motion.
- Configurable Acceleration and Deceleration: Supports ramp times from 0 to 250 seconds for smooth motion profiles.
The CJ1W-NC213 delivers the reliability and precision required for multi-axis positioning and motion control in PLC-based automation systems.
