Omron CQM1-DA022 PLC Analog Output Module 2-Channel ±10V / 0-20mA
- Regular price
- $1,299.00
- Sale price
- $1,299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CQM1-DA022
Description
The Omron CQM1-DA022 is a PLC analog output module designed to convert digital control signals into precise analog voltage or current outputs for industrial automation systems. It provides two analog output channels supporting ±10 V and 0–20 mA signal ranges. This module enables programmable logic controllers to control actuators, drives, and process equipment requiring analog control signals.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | PLCs/Machine Control |
| Part Number | CQM1-DA022 |
| Subcategory | PLC Module/Rack |
| Series | CQM1 Series |
| Module Type | Analog Output Module |
| Number of Outputs | 2 Analog Outputs |
| Output Voltage Range | -10 V to +10 V |
| Output Current Range | 0 to 20 mA |
| Resolution (Voltage) | 12-bit |
| Resolution (Current) | 11-bit |
| Conversion Speed | 0.5 ms / 2 channels |
| Load Impedance (Voltage) | > 2 kΩ |
| Load Impedance (Current) | < 350 Ω |
| Accuracy | ±0.5% at 25°C |
| Insulation | 500 VAC between outputs and PLC bus |
| Power Consumption | 340 mA at 5 V |
| Country of Origin | Netherlands |
| Weight | 0.31 lbs |
Information About CQM1-DA022
The CQM1-DA022 is part of the Omron CQM1 series of PLC expansion modules used in factory automation and machine control applications. It functions as a digital-to-analog converter that translates digital commands from the PLC CPU into analog output signals. The module features two output channels capable of delivering voltage or current signals to external equipment such as variable speed drives, valves, and process control devices. Its compact industrial design, integrated DC/DC converter, and high conversion speed allow reliable performance in automated control systems.
Key Features:
-
Dual Analog Output Channels: Provides two independent analog outputs for flexible process control.
-
Voltage and Current Output Support: Supports ±10 V voltage output and 0–20 mA current output signals.
-
Digital-to-Analog Conversion: Converts PLC digital data into analog control signals for field devices.
-
High Conversion Speed: Processes both channels with a conversion time of approximately 0.5 ms.
-
High Resolution Output: 12-bit resolution for voltage and 11-bit resolution for current outputs.
-
Integrated Power Conversion: Built-in DC/DC converter simplifies installation and wiring.
-
Industrial Accuracy: Typical accuracy of 0.5% at 25°C and 1% across the operating temperature range.
-
Electrical Isolation: 500 VAC insulation between outputs and PLC bus improves noise protection.
The CQM1-DA022 delivers the reliability and precision required for analog signal control in PLC-based industrial automation systems.
