Omron F3SG-4RE0590P30 Safety Light Curtain Hand Protection Sensor
- Regular price
- $3,099.00
- Sale price
- $3,099.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: F3SG-4RE0590P30
Description
The Omron F3SG-4RE0590P30 is a safety light curtain designed to provide reliable hand and arm protection in industrial automation environments. It features 28 infrared beams with 10 mm beam spacing for accurate presence detection and machine safeguarding. This light curtain is commonly used in manufacturing systems requiring high-level operator safety and dependable object detection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation |
| Part Number | F3SG-4RE0590P30 |
| Subcategory | Safety Light Curtains |
| Product Type | Safety Light Curtain |
| Series | F3SG-R |
| Input Voltage | 24 V DC |
| Protected Height | 590 mm |
| Beam Spacing | 10 mm |
| Number of Beams | 28 |
| Maximum Sensing Distance | 20 m (65 ft) |
| Safety Output Rating | 300 mA @ 24 VDC |
| Light Source | 870 nm Infrared LED |
| Auxiliary Output Type | PNP |
| Connection Type | M12, 4-Pin |
| Housing Material | Aluminum |
| Protection Rating | IP65 / IP67 |
| Operating Temperature | -10°C to +55°C |
| Response Time | 5 to 15 ms (On to Off) |
| Mounting Accessories | Mounting Bracket Included |
| Weight | 6.00 lbs |
Information About F3SG-4RE0590P30
The F3SG-4RE0590P30 is part of Omron’s F3SG-R series of safety light curtains, developed for advanced machine safety applications. It operates on a 24 VDC supply and uses infrared LED technology to create a protective sensing field across a 590 mm protected height. The unit features PNP auxiliary outputs and M12 connector interfaces for integration into industrial control systems. Designed with an aluminum housing and IP65/IP67 protection ratings, it ensures reliable performance in demanding industrial environments.
Key Features:
- 590 mm Protective Height: Provides reliable hand and arm protection coverage
- 28 Beam Configuration: Ensures accurate detection across the sensing area
- 10 mm Beam Spacing: Enables precise object and operator detection
- 24 VDC Operation: Compatible with industrial automation systems
- Long Sensing Distance: Supports detection ranges up to 20 m (65 ft)
- IP65/IP67 Protection: Resistant to dust and water ingress
- Infrared LED Technology: Uses 870 nm IR LEDs for stable sensing performance
- M12 Connections: Simplifies installation and industrial integration
The F3SG-4RE0590P30 delivers the reliability and precision required for machine safeguarding and operator protection in industrial automation systems.
