Omron NS5-TQ10-V2 5.7" TFT Touchscreen HMI Operator Interface Panel 24VDC
- Regular price
- $2,119.00
- Sale price
- $2,119.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NS5-TQ10-V2
Description
The Omron NS5-TQ10-V2 is a programmable touchscreen operator interface designed for monitoring and controlling industrial automation equipment. It features a 5.7-inch color TFT LCD display with a resolution of 320 × 240 pixels, enabling clear visualization of machine data and process information. Powered by a 24 VDC supply, this HMI terminal provides an interactive interface between operators and PLC-based control systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | HMI / MMI / OIT |
| Part Number | NS5-TQ10-V2 |
| Subcategory | Operator Interface |
| Series | NS |
| Display Type | Color TFT LCD |
| Display Size | 5.7 inches |
| Resolution | 320 × 240 pixels |
| Color Support | 256 colors |
| Input Method | Touchscreen |
| Communication Ports | 2 × RS-232C |
| Supply Voltage | 24 VDC |
| Memory Capacity | 60 MB screen memory |
| Ingress Protection | IP65 (front panel) |
| Operating Temperature | 0°C to 50°C |
| Mounting Type | Panel mount |
| Weight | 1.87 lbs |
Information About NS5-TQ10-V2
The NS5-TQ10-V2 is part of the Omron NS series of programmable terminals developed for industrial automation and machine control environments. It integrates a color touchscreen display with built-in memory for storing graphical screens, system data, and application programs. The terminal communicates with automation controllers through serial communication interfaces such as RS-232C, allowing connection to PLCs and other control devices. Designed for panel-mounted installation, the unit provides reliable operation in control cabinets used across manufacturing and process automation systems.
Key Features:
-
5.7-Inch TFT Color Display: Provides clear visualization of machine status and control screens.
-
320 × 240 Pixel Resolution: Enables detailed graphics and operator interface screens.
-
Touchscreen Operation: Allows direct operator input for system monitoring and control.
-
Large Screen Memory: Includes 60 MB memory for storing interface screens and application data.
-
Dual RS-232C Communication Ports: Enables connection to PLCs and industrial control devices.
-
Industrial Panel Mount Design: Designed for installation within control cabinets and operator panels.
-
IP65 Front Protection: Dust-tight and water-resistant front panel suitable for industrial environments.
-
NS Series Integration: Compatible with Omron PLC platforms and NS programming tools.
The NS5-TQ10-V2 delivers the reliability and precision required for operator interface control and visualization in industrial automation systems.
