Omron NX-PG0332-5 Pulse Output Unit for Motion Control
- Regular price
- $809.00
- Sale price
- $809.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NX-PG0332-5
Description
The Omron NX-PG0332-5 is a high-speed pulse output unit designed for precise open-loop motion control in industrial automation systems. It provides accurate pulse generation for controlling servo drives and stepper motor drives, making it ideal for positioning, indexing, and synchronized machine movement in packaging, material handling, and manufacturing applications.
Technical Specifications
| Condition | New / Surplus Available |
| Brand | Omron |
| Part Number | NX-PG0332-5 |
| Category | Industrial Automation and Controls |
| Subcategory | Pulse Output Module |
| Product Type | Pulse Output Unit |
| Series | NX |
| I/O System | NX I/O Bus |
| Module Type | Pulse Output |
| Pulse Output Channels | 4 |
| Maximum Pulse Output Frequency | 4,000 kHz (4 MHz) |
| Digital Output Types | Line Driver (RS-422), NPN, Voltage Pulse |
| Signal Processing | Synchronous or Task Period Prioritized |
| Control Method | Open-Loop Pulse Control |
| Controlled Devices | Servo Drives and Stepper Motor Drives |
| External Connection | MIL Connector (34-pin ×2) |
| Number of I/O Connectors | 2 |
| Degree of Protection | IP20 |
| Mounting Type | DIN Rail |
| Operating Method | Synchronous I/O Refreshing or Task-Priority Refreshing |
| Position Control Range | -2,147,483,648 to +2,147,483,647 Pulses |
| Velocity Control Range | 1 to 4,000,000 pps |
| Dimensions (H × W × D) | 100 × 30 × 89.8 mm |
| Weight | 0.33 lbs |
Information About NX-PG0332-5
The NX-PG0332-5 is part of Omron's NX Series I/O platform and is engineered for advanced pulse-based motion control. It features four pulse output channels with line driver, NPN, and voltage pulse outputs, supporting multiple pulse output methods and output frequencies up to 4 MHz. The unit communicates through the NX I/O Bus and supports synchronous I/O refreshing for highly accurate machine synchronization. Its compact DIN rail-mounted design integrates seamlessly into Sysmac automation systems, providing flexible control of servo and stepper motor drives.
Key Features:
- NX Series Pulse Output Unit for motion control
- Four independent pulse output channels
- Maximum pulse output frequency of 4 MHz
- Supports Line Driver (RS-422), NPN, and Voltage Pulse outputs
- Compatible with servo drives and stepper motor drives
- Synchronous or task-prioritized signal processing
- MIL connector interface for industrial wiring
- Open-loop positioning and speed control
- Compact DIN rail mounting design
- Designed for high-speed industrial automation systems
The NX-PG0332-5 delivers reliable, high-speed pulse control for precise industrial motion applications.
