Omron NX502-1300 Machine Automation Controller for Motion Control
- Regular price
- $5,247.00
- Sale price
- $5,247.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NX502-1300
Description
The Omron NX502-1300 is a high-performance machine automation controller (PAC) designed to integrate sequence control, motion control, database connectivity, and industrial networking into a single platform. Built for demanding automation applications, it delivers exceptional processing speed, synchronized multi-axis motion control, and advanced communication capabilities for modern manufacturing systems.
Technical Specifications
| Condition | New / Surplus Available |
| Brand | Omron |
| Part Number | NX502-1300 |
| Category | Industrial Automation and Controls |
| Subcategory | Programmable Controllers (PLC / PAC) |
| Product Type | Machine Automation Controller |
| Series | NX |
| Controller Functions | Sequence Control, Motion Control, SQL Database, OPC UA |
| Supply Voltage | 24 VDC |
| Primary Task Cycle Time | 0.250 ms |
| Program Memory | 80 MB |
| Variable Memory | 260 MB |
| Maximum Motion Axes | 32 (16 Synchronized) |
| Communication Ports | EtherCAT Master, EtherNet/IP, Ethernet TCP/IP |
| Communication Options | EtherCAT Slave, Ethernet TCP/IP, IO-Link, RS-232C, RS-422, RS-485 |
| Maximum Remote I/O Nodes | 256 |
| I/O System | NX I/O Bus |
| Maximum Expansion Units | 63 |
| Number of Inputs | 16 |
| Number of Outputs | 16 |
| Mounting Type | DIN Rail |
| Operating Temperature | 0°C to +55°C |
| Display | No Display |
| Weight | 2.09 lbs |
Information About NX502-1300
The NX502-1300 is part of Omron's NX Series Sysmac platform, engineered for advanced machine automation and Industry 4.0 applications. It combines PLC functionality, motion control, OPC UA connectivity, SQL database communication, and EtherCAT networking in one controller. With an ultra-fast 0.25 ms primary task cycle, support for up to 32 motion axes, and 80 MB of program memory, the controller enables highly synchronized and data-driven machine control. Its scalable architecture supports up to 63 expansion units and 256 remote I/O nodes, making it ideal for complex industrial automation systems.
Key Features:
- NX Series Machine Automation Controller (PAC)
- Integrated sequence, motion, database, and OPC UA control
- Supports up to 32 motion axes (16 synchronized axes)
- Ultra-fast 0.25 ms primary task cycle
- Built-in EtherCAT Master and EtherNet/IP communications
- SQL database connectivity for production data management
- 80 MB program memory and 260 MB variable memory
- Supports up to 63 expansion modules and 256 remote I/O nodes
- DIN rail mounting for industrial control panels
- Designed for high-performance manufacturing and machine automation
The NX502-1300 delivers powerful machine control, real-time networking, and scalable automation for advanced industrial applications.
