R88M-K75030T-S2 | Omron Accurax G5 750W AC Servo Motor 3000RPM Absolute Encoder
- Regular price
- $1,777.00
- Sale price
- $1,777.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: R88M-K75030T-S2
Description
The Omron R88M-K75030T-S2 is a 750 W AC servomotor from the Accurax G5 series designed for precise motion control in industrial automation systems. It operates at a rated speed of 3000 RPM and provides accurate positioning through an integrated absolute encoder. This servo motor is commonly used in applications such as packaging machinery, robotics, and automated manufacturing equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Servo Products |
| Part Number | R88M-K75030T-S2 |
| Subcategory | Servo Motor |
| Series | Accurax G5 |
| Motor Type | AC Servomotor |
| Rated Power | 750 W |
| Rated Voltage | 230 VAC |
| Rated Speed | 3000 RPM |
| Rated Torque | 2.4 Nm |
| Maximum Torque | 7.1 Nm |
| Encoder Type | Absolute encoder |
| Flange Size | 80 × 80 mm |
| Shaft Diameter | 19 mm |
| Shaft Length | 35 mm |
| Mounting Hole Spacing | 90 mm |
| Termination Style | Connector |
| Operating Temperature | 0°C to 40°C |
| Weight | 5 lbs |
Information About R88M-K75030T-S2
The R88M-K75030T-S2 is part of Omron’s Accurax G5 servo system designed for high-performance motion control in industrial automation. It is engineered to operate with compatible Omron G5 servo drives to deliver stable torque, precise positioning, and smooth motion control. The motor features an absolute encoder that enables accurate position feedback and eliminates the need for homing after power cycles. Its compact 80 mm square flange design and keyed shaft allow easy integration into automated machinery and motion systems.
Key Features:
-
Accurax G5 Servo System Compatibility: Designed to operate with Omron G5 series servo drives for advanced motion control.
-
High Power Output: Provides 750 W rated output suitable for medium-power automation applications.
-
High-Speed Operation: Rated speed of 3000 RPM ensures efficient and responsive motion control.
-
Absolute Encoder Feedback: Integrated absolute encoder enables precise position tracking.
-
High Peak Torque Capability: Delivers up to 7.1 Nm maximum momentary torque for dynamic motion requirements.
-
Compact Mechanical Design: 80 mm square flange allows installation in space-constrained machinery.
-
Keyed Shaft Configuration: Ensures secure mechanical coupling with drive systems.
-
Industrial Compliance Certifications: Meets CE, CSA, UL, and TÜV safety standards.
The R88M-K75030T-S2 delivers the reliability and precision required for high-performance motion control in industrial automation systems.
