Omron SRT2-ROC08 8-Point CompoBus/S Relay Output Module
- Regular price
- $397.00
- Sale price
- $397.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SRT2-ROC08
Description
The Omron SRT2-ROC08 is an 8-point relay remote output module designed for CompoBus/S distributed I/O systems. It provides reliable relay outputs for industrial automation applications, allowing PLCs to control field devices over high-speed remote I/O networks while simplifying installation and maintenance.
Technical Specifications
| Condition | Obsolete / Surplus Available |
| Brand | Omron |
| Part Number | SRT2-ROC08 |
| Category | PLCs / Machine Control |
| Subcategory | PLC Module / Rack |
| Product Type | Relay Remote Output Module |
| Series | SRT2 |
| Communication | CompoBus/S |
| Number of Outputs | 8 Relay Outputs |
| Relay Type | G6D-1A (Replaceable) |
| Rated Voltage | 24 VDC |
| Rated Load | 3 A @ 250 VAC, 3 A @ 30 VDC (Resistive) |
| Maximum Contact Voltage | 250 VAC / 30 VDC |
| Maximum Contact Current | 3 A |
| Maximum Switching Capacity | 730 VA (AC), 90 W (DC) |
| Power Supply Range | 24 VDC (+10% / -15%) |
| Current Consumption | 350 mA Max. |
| Connection Method | Multi-drop or T-branch |
| Termination Style | Screw Terminal |
| Mounting Type | DIN Rail / Panel Mount |
| Operating Temperature | 0°C to +55°C |
| Approvals | CE, CSA, UL |
| Part Status | Obsolete |
| Weight | 0.31 lbs |
Information About SRT2-ROC08
The SRT2-ROC08 is part of Omron's SRT2 Series remote I/O platform for CompoBus/S networks. It features eight independent relay outputs, each using a replaceable G6D-1A relay capable of switching loads up to 3 A. Supporting both multi-drop and T-branch network topologies, the module enables flexible distributed control in industrial automation systems. Its DIN rail or panel mounting options, removable relays, and compact design make it suitable for machine control, factory automation, and process applications. Although discontinued, it remains widely used in existing CompoBus/S installations.
Key Features:
- SRT2 Series remote relay output module
- 8 relay output points
- CompoBus/S distributed I/O communication
- Replaceable G6D-1A relay outputs
- 24 VDC operating voltage
- Up to 3 A switching capacity per output
- Supports multi-drop and T-branch network wiring
- DIN rail or panel mounting
- Screw terminal connections
- Designed for industrial automation and remote I/O systems
The SRT2-ROC08 delivers dependable remote relay output control for Omron CompoBus/S automation networks.
