OS32C-SN-4M | Omron Safety Laser Scanner
- Regular price
- $5,197.00
- Sale price
- $5,197.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: OS32C-SN-4M
Description
The Omron OS32C-SN-4M is a compact, high-performance safety laser scanner sensor block designed for industrial safety applications. With a 4-meter safety range and a 270° scanning angle, it provides reliable area monitoring to protect personnel and equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Omron |
| Category |
Safety Systems
|
| Part Number | OS32C-SN-4M |
| Subcategory | Safety Controller |
| Series | OS32C |
| Component Type | Sensor Block (without I/O block) |
| Safety Type | Type 3 Safety Laser Scanner |
| Safety Category | PLd / Category 3 (ISO 13849-1) |
| Safety Range | Up to 4 meters |
| Warning Zone Range | Up to 15 meters |
| Scanning Angle | 270° |
| Detection Resolution | Configurable: 30, 40, 50, or 70 mm |
| Angular Resolution | 0.4° |
| Response Time | 80 ms to 680 ms (configurable) |
| Power Supply | 24 VDC ±25% |
| Power Consumption | 5 W max. |
| Storage Temperature | -25°C to 70°C |
| Operating Temperature | -10°C to 50°C |
| Humidity | 95% RH max., non-condensing |
| Enclosure Rating | IP65 |
| Dimensions (WxHxD) | 5.24 x 4.11 x 5.62 inches (133 x 104.5 x 142.7 mm) |
| Housing Material | Die-cast aluminum |
| Optical Cover Material | Polycarbonate |
| Approvals | IEC 61496-1/-3, ISO 13849-1, UL, CE |
| Weight | 2.60 lbs |
Information About OS32C-SN-4M
The OS32C-SN-4M is a sensor block component of Omron's OS32C series safety laser scanners, intended as a replacement unit without an I/O block. It offers a configurable detection resolution of 30, 40, 50, or 70 mm, allowing for precise detection tailored to specific application requirements. The device's compact design facilitates easy integration into various industrial environments, and its robust construction ensures durability under challenging conditions. This model is suitable for applications requiring reliable intrusion detection and area safeguarding.
Key Features:
- Extended Safety Range: Provides a safety detection range of up to 4 meters for comprehensive area coverage.
- Wide Scanning Angle: Features a 270° scanning angle to monitor broad areas with a single unit.
- Configurable Resolution: Allows selection of 30, 40, 50, or 70 mm detection resolution to suit specific safety requirements.
- Compact Design: Small footprint enables installation in space-constrained environments.
- Robust Construction: Built to withstand industrial conditions, ensuring long-term reliability.
- Easy Integration: Designed for seamless replacement in existing OS32C series installations without the need for reprogramming.
- Visual Indicators: Equipped with multiple LED indicators for quick status assessment.
- Compliance: Meets international safety standards, including IEC 61496-1/-3 and ISO 13849-1.
The OS32C-SN-4M delivers the reliability and precision required for safeguarding personnel and equipment in industrial environments.
Description
The Omron OS32C-SN-4M is a compact, high-performance safety laser scanner sensor block designed for industrial safety applications. With a 4-meter safety range and a 270° scanning angle, it provides reliable area monitoring to protect personnel and equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Omron |
| Category |
Safety Systems
|
| Part Number | OS32C-SN-4M |
| Subcategory | Safety Controller |
| Series | OS32C |
| Component Type | Sensor Block (without I/O block) |
| Safety Type | Type 3 Safety Laser Scanner |
| Safety Category | PLd / Category 3 (ISO 13849-1) |
| Safety Range | Up to 4 meters |
| Warning Zone Range | Up to 15 meters |
| Scanning Angle | 270° |
| Detection Resolution | Configurable: 30, 40, 50, or 70 mm |
| Angular Resolution | 0.4° |
| Response Time | 80 ms to 680 ms (configurable) |
| Power Supply | 24 VDC ±25% |
| Power Consumption | 5 W max. |
| Storage Temperature | -25°C to 70°C |
| Operating Temperature | -10°C to 50°C |
| Humidity | 95% RH max., non-condensing |
| Enclosure Rating | IP65 |
| Dimensions (WxHxD) | 5.24 x 4.11 x 5.62 inches (133 x 104.5 x 142.7 mm) |
| Housing Material | Die-cast aluminum |
| Optical Cover Material | Polycarbonate |
| Approvals | IEC 61496-1/-3, ISO 13849-1, UL, CE |
| Weight | 2.60 lbs |
Information About OS32C-SN-4M
The OS32C-SN-4M is a sensor block component of Omron's OS32C series safety laser scanners, intended as a replacement unit without an I/O block. It offers a configurable detection resolution of 30, 40, 50, or 70 mm, allowing for precise detection tailored to specific application requirements. The device's compact design facilitates easy integration into various industrial environments, and its robust construction ensures durability under challenging conditions. This model is suitable for applications requiring reliable intrusion detection and area safeguarding.
Key Features:
- Extended Safety Range: Provides a safety detection range of up to 4 meters for comprehensive area coverage.
- Wide Scanning Angle: Features a 270° scanning angle to monitor broad areas with a single unit.
- Configurable Resolution: Allows selection of 30, 40, 50, or 70 mm detection resolution to suit specific safety requirements.
- Compact Design: Small footprint enables installation in space-constrained environments.
- Robust Construction: Built to withstand industrial conditions, ensuring long-term reliability.
- Easy Integration: Designed for seamless replacement in existing OS32C series installations without the need for reprogramming.
- Visual Indicators: Equipped with multiple LED indicators for quick status assessment.
- Compliance: Meets international safety standards, including IEC 61496-1/-3 and ISO 13849-1.
The OS32C-SN-4M delivers the reliability and precision required for safeguarding personnel and equipment in industrial environments.
