PDG4XPXR30800B2N | Eaton 800A Power Defense Trip Unit
- Regular price
- $2,125.00
- Sale price
- $2,125.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: PDG4XPXR30800B2N
Description
Eaton PDG4XPXR30800B2N is a Power Defense Frame 4 accessory trip unit with an 800 A electronic PXR10 LSI (Long‑Time, Short‑Time & Instantaneous) protection module.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Eaton |
| Category |
Circuit Breakers
|
| Part Number | PDG4XPXR30800B2N |
| Subcategory | Molded Case Circuit Breakers |
| Amperage Rating |
800 A |
| Frame | 4 |
| Number of Poles |
Three-pole
|
| Circuit Breaker Type | PD4 Global |
| Frame Size | Frame J-K |
| Series |
Power Defense
|
| Trip Type |
PXR10 LSI
|
| Technology |
Electronic
|
| Rated Voltage (UL) | 600 VAC |
| Rated Voltage (IEC) | 690 V |
| Interrupting Capacity | 65 kA @ 480 VAC (UL) |
| Global Certifications | UL 489, IEC 60947-2, CSA, CCC, RoHS |
| Mounting Compatibility | Compatible with Power Defense Frame PD4 units |
| Length/Depth | 222.3 mm |
| Height | 139.7 mm |
| Width | 136.5 mm |
| Weight | 1.0 kgs |
Information About PDG4XPXR30800B2N
The PDG4XPXR30800B2N is part of Eaton’s Power Defense molded case circuit breaker series—advanced, globally certified solutions engineered for precise, intelligent circuit protection. This 800 A electronic trip unit is designed for use with 3-pole Power Defense Frame 4 (PDG4) breakers and features the Power Xpert Release (PXR10) platform, offering solid-state LSI (Long-Time, Short-Time, Instantaneous) protection. Built for demanding industrial environments, it combines robust overcurrent protection with integrated diagnostics, metering, and communication capability.
Key Features:
- Electronic LSI Protection: Delivers adjustable long-time, short-time, and instantaneous trip functionality for tailored circuit protection in critical systems.
- High Current Rating: Supports continuous operation at 800 A, ideal for large distribution panels, switchgear, and industrial mains.
- Smart Monitoring: PXR10 trip unit offers real-time current metering, event logs, cause-of-trip data, and enhanced system visibility when paired with PXPM software.
- Digital Connectivity: USB interface enables configuration and diagnostics via Eaton’s PXPM software; expandable for advanced communication protocols (Modbus, Ethernet, Profibus).
- Global Compliance: Certified to UL 489, IEC 60947-2, CSA, CCC, and RoHS standards, enabling worldwide deployment in regulated environments.
- Compact Integration: Designed for easy installation into PDG4 circuit breakers, with a space-efficient footprint (~222 × 140 × 137 mm) and minimal weight (~1 kg).
- Expandable Protection: Supports zone-selective interlocking (ZSI) and optional ground fault detection for improved system coordination and safety.
- Reliable Build: Solid-state electronics housed in a rugged enclosure, optimized for performance in high-demand industrial and commercial settings.
- Flexible Application: Ideal for heavy-duty electrical systems in manufacturing plants, data centers, commercial facilities, and infrastructure projects.
- Maintenance Efficiency: Provides advanced trip analytics and programmable thresholds to reduce nuisance trips and improve uptime.
The Eaton PDG4XPXR30800B2N trip unit delivers precision protection, intelligent diagnostics, and global standards compliance for high-current applications—making it an excellent upgrade path for system designers and engineers building smarter, safer power distribution systems.
