Pepperl+Fuchs ENI58IL-H12BA5-1024UD1-RC1 Incremental Encoder
- Regular price
- $455.00
- Sale price
- $455.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ENI58IL-H12BA5-1024UD1-RC1
Description
The Pepperl+Fuchs ENI58IL-H12BA5-1024UD1-RC1 is an incremental rotary encoder designed to measure rotational movement and provide position and speed feedback to industrial control systems. With a resolution of 1,024 pulses per revolution and a hollow-shaft construction, it is suitable for integration into compatible motors, machinery, and automation equipment. Its universal output-driver technology supports signal transmission to compatible controllers and motion-control systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Pepperl+Fuchs |
| Category | Sensors & Instrumentation |
| Part Number | ENI58IL-H12BA5-1024UD1-RC1 |
| Subcategory | Incremental Rotary Encoders |
| Product Family | ENI58IL-H |
| Product Type | Optical Incremental Rotary Encoder |
| Resolution | 1,024 pulses per revolution (PPR) |
| Shaft Type | Hollow shaft |
| Housing Diameter | 58.5 mm |
| Operating Voltage | 4.75–30 V DC (family specification) |
| Output Type | Push-pull or RS-422, depending on configuration |
| Maximum Output Frequency | 400 kHz (family specification) |
| Protection Rating | Verify exact model variant |
| Maximum Rotational Speed | Verify exact model variant |
| Weight | 0.66 lb |
Information About ENI58IL-H12BA5-1024UD1-RC1
The ENI58IL-H12BA5-1024UD1-RC1 belongs to Pepperl+Fuchs' ENI58IL-H series of optical incremental rotary encoders. The encoder converts shaft rotation into electrical pulse signals that controllers can use to determine movement and rotational speed. The ENI58IL-H family supports push-pull or RS-422 output, depending on the configured model and supply voltage. Its metal housing and hollow shaft are intended for industrial installation, with the exact mounting and connector arrangement determined by the full model code.
Key Features:
-
1,024 PPR Resolution: Provides 1,024 pulses per revolution for rotational feedback.
-
Incremental Measurement: Generates pulse signals representing shaft movement.
-
Hollow-Shaft Design: Allows mounting onto a compatible shaft without a separate solid-shaft coupling arrangement.
-
58 mm-Class Housing: Fits industrial encoder installations designed for this housing size.
-
Universal Output Driver: Supports push-pull or RS-422 signaling, depending on configuration.
-
Wide Supply Range: The ENI58IL-H family supports 4.75–30 V DC.
-
High Output Frequency: Family specifications list output frequencies up to 400 kHz.
-
Industrial Protection: The family includes IP65/IP67 variants; confirm the exact model's rating before installation.
The ENI58IL-H12BA5-1024UD1-RC1 delivers precise incremental feedback for compatible industrial motion-control and automation applications.
