Pepperl+Fuchs KFD2-HMM-16 16-Channel HART Multiplexer Master Module
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: KFD2-HMM-16
Description
The Pepperl+Fuchs KFD2-HMM-16 is a 16-channel HART multiplexer master designed to interface HART-enabled field devices with industrial process control and asset management systems. It operates from a 24 VDC Power Rail supply and supports HART communication revisions 5 through 7 for centralized access to field device data.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Pepperl+Fuchs |
|
Category |
Control Components |
|
Part Number |
KFD2-HMM-16 |
|
Subcategory |
Signal Isolators and Switch Amplifiers |
|
Product Type |
HART Multiplexer Master |
|
Series |
K-System |
|
Number of Channels |
16 |
|
Communication Protocol |
HART |
|
Supported HART Revisions |
5–7 |
|
Supply Type |
24 VDC Power Rail |
|
Rated Voltage Range |
20–32 VDC |
|
Typical Current |
100 mA |
|
Maximum Power Consumption |
3 W |
|
Expandable Modules |
Up to 15 KFD0-HMS-16 secondary modules |
|
Mounting |
DIN rail |
|
Ambient Temperature |
-20 to 60 °C (-4 to 140 °F) |
|
Safety Integrity Level |
Up to SIL 3 according to IEC/EN 61508, subject to system requirements |
|
Connection Terminals |
17+ and 18- |
|
Item Number |
231289 |
|
Dimensions |
0.269 × 0.267 × 0.11 in |
|
Weight |
0.23 kg |
Information About KFD2-HMM-16
The KFD2-HMM-16 belongs to the Pepperl+Fuchs K-System and serves as the primary module in a HART multiplexer architecture. It supports connection to up to 15 KFD0-HMS-16 secondary modules, allowing the system to expand its HART communication capacity. The module has a rated supply voltage of 20–32 VDC, a typical current of 100 mA, and a maximum power consumption of 3 W. Designed for DIN-rail installation, it is specified for safety applications up to SIL 3 in accordance with IEC/EN 61508 when used under the applicable system conditions.
Key Features:
-
16-channel HART multiplexing: Provides communication access to HART-enabled field devices across 16 channels.
-
HART protocol support: Supports field device communication revisions 5 through 7.
-
24 VDC Power Rail supply: Integrates with compatible Pepperl+Fuchs K-System Power Rail installations.
-
Expandable architecture: Supports connection to up to 15 KFD0-HMS-16 secondary modules.
-
Low power consumption: Uses a maximum of 3 W under specified operating conditions.
-
DIN-rail mounting: Supports installation in industrial control cabinets.
-
Safety capability: Specified for use in applications up to SIL 3 according to IEC/EN 61508, subject to system requirements.
-
Industrial temperature range: Supports ambient operation from -20 to 60 °C.
The KFD2-HMM-16 delivers the reliability and precision required for industrial HART communication, field device integration, and process instrumentation management.
