Pepperl+Fuchs KFU8-SR-EX2.W Two-Channel Switch Amplifier
- Regular price
- $259.00
- Sale price
- $259.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: KFU8-SR-EX2.W
Description
The Pepperl+Fuchs KFU8-SR-EX2.W is a two-channel switch amplifier and isolated barrier designed to transfer digital signals from hazardous areas to safe-area control systems. It accepts NAMUR sensors or dry-contact inputs and provides relay switching, line fault detection, and configurable operating logic for industrial process automation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Pepperl+Fuchs |
| Category | Industrial Automation & Control |
| Part Number | KFU8-SR-EX2.W |
| Subcategory | Switch Amplifiers & Intrinsic Safety Barriers |
| Product Series | K-System |
| Device Type | Two-channel switch amplifier / isolated barrier |
| Number of Channels | 2 |
| Input Types | NAMUR sensors and dry contacts |
| Input Standard | EN 60947-5-6 (NAMUR) |
| Rated Supply Voltage | 19–30 V DC or 90–253 V AC, 50–60 Hz |
| Power Consumption | ≤1.3 W DC; 3.6 VA AC |
| Output Type | Signal output and relay output |
| Relay Contact Rating | 250 V AC / 2 A; 126.5 V AC / 4 A; 40 V DC / 2 A resistive |
| Minimum Switching Current | 2 mA at 24 V DC |
| Switching Frequency | ≤10 Hz |
| Line Fault Detection | Detects open circuit at ≤0.1 mA and short circuit at >6 mA |
| Switching Delay | Approximately 20 ms energizing and de-energizing |
| Functional Safety | SIL 2, systematic capability SC 3 |
| Galvanic Isolation | Reinforced isolation; rated insulation voltage 300 V RMS |
| Configuration | DIP switches |
| Mounting | 35 mm DIN rail |
| Connection | Screw terminals |
| Protection Rating | IP20 |
| Operating Temperature | −40°C to +60°C; extended range to +70°C under specified mounting conditions |
| Dimensions (W × H × D) | 20 × 119 × 115 mm |
| Weight | 0.331 lb |
Information About KFU8-SR-EX2.W
The KFU8-SR-EX2.W is a K-System switch amplifier from Pepperl+Fuchs designed for intrinsically safe signal transmission. It supports two input channels and accepts NAMUR proximity sensors or mechanical dry contacts. The module provides relay outputs with reversible switching logic and line fault detection for open-circuit and short-circuit conditions. It supports both 19–30 V DC and 90–253 V AC supply voltages and offers SIL 2 functional safety capability.
-
Two-Channel Design: Processes two digital input channels within one module.
-
Intrinsically Safe Interface: Transfers signals from compatible hazardous-area devices.
-
Input Compatibility: Accepts NAMUR sensors and dry-contact switches.
-
Relay Outputs: Provides changeover relay contacts for control-side switching.
-
Line Fault Detection: Detects open circuits and short circuits on the field input.
-
Reversible Logic: Allows the normal output switching state to be changed using DIP switches.
-
Universal Power Supply: Supports specified AC and DC supply ranges.
-
Functional Safety: Rated up to SIL 2 with systematic capability SC 3.
The KFU8-SR-EX2.W delivers the reliability and precision required for hazardous-area signal conditioning, process monitoring, and industrial control systems.
