Pepperl+Fuchs NCN50-FP-W-P4 Inductive Proximity Sensor 50 mm AC
- Regular price
- $642.00
- Sale price
- $642.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NCN50-FP-W-P4
Description
The Pepperl+Fuchs NCN50-FP-W-P4 is an inductive proximity sensor from the Comfort series, designed for non-contact detection of metallic objects at a rated operating distance of 50 mm. It uses a two-wire AC output with normally open/normally closed switching functionality and supports operating voltages from 20 to 253 V AC for industrial sensing and control applications.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Pepperl+Fuchs |
|
Category |
Control Components |
|
Part Number |
NCN50-FP-W-P4 |
|
Subcategory |
Inductive Proximity Sensors |
|
Manufacturer Part Number |
182960 |
|
Product Series |
Comfort |
|
Rated Operating Distance (Sn) |
50 mm |
|
Assured Operating Distance (Sa) |
0–40.5 mm |
|
Output Configuration |
Two-wire AC |
|
Switching Function |
Normally open/normally closed (NO/NC) |
|
Operating Voltage |
20–253 V AC |
|
Maximum Load Current |
500 mA |
|
Switching Frequency |
0–20 Hz |
|
Connection Type |
Screw terminals |
|
Degree of Protection |
IP68 |
|
Reduction Factor (Aluminum) |
0.4 |
|
Reduction Factor (Copper) |
0.3 |
|
Reduction Factor (Stainless Steel 304) |
0.85 |
|
Approvals |
cCSAus, cULus |
|
Weight |
0.19 lb |
Information About NCN50-FP-W-P4
The NCN50-FP-W-P4 belongs to the Pepperl+Fuchs inductive proximity sensor family and features a non-flush mounting configuration for detecting metal targets within its specified sensing range. Its two-wire AC switching design allows integration into compatible industrial control circuits without requiring a separate conventional three-wire sensor output arrangement. Screw-terminal connections provide a direct wiring interface, while the integrated status indicator helps identify sensor operating conditions. The sensor also incorporates short-circuit protection and carries cCSAus and cULus approvals as specified in the available product information.
Key Features:
-
Inductive sensing technology: Detects metallic objects without direct physical contact.
-
50 mm rated sensing distance: Provides a nominal operating distance of 50 mm for proximity detection.
-
Non-flush installation: Supports mounting configurations where the sensing face is not embedded flush in surrounding metal.
-
Two-wire AC output: Connects to compatible AC switching circuits using a two-wire configuration.
-
NO/NC switching functionality: Supports normally open/normally closed switching behavior as specified.
-
Wide operating voltage: Accepts a supply voltage range of 20–253 V AC.
-
Screw-terminal connection: Provides terminals for electrical installation and wiring.
-
Industrial protection and approvals: Features IP68 protection, short-circuit protection, and specified cCSAus and cULus approvals.
The NCN50-FP-W-P4 delivers the reliability and precision required for non-contact metal detection in industrial automation and machine control systems.
