Pepperl+Fuchs NJ2-PD-US-2.062-V93 Inductive Cylinder Sensor
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NJ2-PD-US-2.062-V93
Description
The Pepperl+Fuchs NJ2-PD-US-2.062-V93 is an inductive cylinder position sensor designed to detect metallic targets in industrial pneumatic and hydraulic cylinder applications. It provides a 2 mm sensing distance, a two-wire AC/DC switching output, and a normally open switching function. Its weld-immune design, high-pressure capability, and IP67 protection make it suitable for demanding industrial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Pepperl+Fuchs |
| Category | Sensors & Switches |
| Part Number | NJ2-PD-US-2.062-V93 |
| Subcategory | Inductive Proximity Sensors |
| Product Type | Inductive Cylinder Position Switch |
| Sensing Distance | 2 mm |
| Switching Function | Normally Open (NO) |
| Output Type | Two-wire AC/DC |
| Operating Voltage | 20–250 V AC / 20–300 V DC |
| Switching Frequency | 0–20 Hz |
| Operating Current | 8–300 mA AC/DC |
| Maximum Dynamic Pressure | 3,000 psi |
| Protection Rating | IP67 |
| Operating Temperature | -25 to +70 °C |
| Connection | 7/8-inch threaded, 3-pin connector |
| Housing Material | Zinc housing; aluminum probe |
| Weight | 0.47 lb |
Information About NJ2-PD-US-2.062-V93
The NJ2-PD-US-2.062-V93 is a cylinder position switch from Pepperl+Fuchs' inductive sensor range. It uses a flush-mount sensing arrangement and supports operating voltages from 20 to 250 V AC or 20 to 300 V DC. The sensor provides a nominal 2 mm operating distance and supports switching frequencies up to 20 Hz. Its zinc housing, aluminum probe, and 7/8-inch threaded three-pin connector are designed for industrial installation, including applications exposed to welding environments and elevated pressure.
Key Features:
-
Inductive Sensing Technology: Detects metallic targets without physical contact.
-
2 mm Sensing Distance: Provides short-range detection for cylinder position monitoring.
-
Normally Open Output: Uses a normally open switching function.
-
Two-Wire AC/DC Operation: Supports AC and DC switching circuits within the specified voltage ranges.
-
Weld-Immune Design: Suitable for compatible applications exposed to welding fields.
-
High-Pressure Rating: Supports dynamic operating pressure up to 3,000 psi.
-
IP67 Protection: Protects against dust ingress and temporary immersion under specified conditions.
-
Industrial Connector: Uses a three-pin, 7/8-inch threaded connector.
The NJ2-PD-US-2.062-V93 delivers the sensing reliability and rugged construction required for industrial cylinder position detection and automation applications.
