Pepperl+Fuchs UPR-03-S Universal Power Rail 800 mm DIN Rail
- Regular price
- $515.00
- Sale price
- $515.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: UPR-03-S
Description
The Pepperl+Fuchs UPR-03-S is a universal power rail designed to distribute 24 V DC power to compatible K-System interface modules. Its 35 mm DIN mounting rail includes a three-conductor insert, cover, and end caps, simplifying installation and reducing the need for daisy-chained wiring.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Pepperl+Fuchs |
| Category | Industrial Automation |
| Part Number | UPR-03-S |
| Subcategory | Power Distribution Rails |
| Product Type | Universal Power Rail |
| Compatible System | Pepperl+Fuchs K-System |
| Mounting Type | 35 mm DIN rail |
| Number of Conductors | 3 |
| Power Conductors | 2 |
| Fault Signal Conductors | 1 |
| Rated Voltage | 24 V DC |
| Rated Current | 4 A |
| Standard Length | 800 mm (31.5 in) |
| Dimensions (W × H × L) | 35 × 15 × 800 mm |
| Ambient Temperature | −40 to +70 °C (−40 to +158 °F) |
| Included Components | UPR-MR DIN rail, UPR-INS-03 insert, UPR-COVER, UPR-E end caps |
| Weight | 1.1 lb |
Information About UPR-03-S
The UPR-03-S is a universal power rail for Pepperl+Fuchs K-System modules. It provides two conductors for power distribution and one conductor for collective fault signaling. The rail is rated for 24 V DC and a maximum current of 4 A. Its standard length is 800 mm and can be shortened to suit the installation.
-
Product Type: Universal power rail for K-System interface modules.
-
Mounting: Standard 35 mm DIN rail.
-
Conductor Configuration: Three conductors, including two for power and one for collective fault signaling.
-
Rated Voltage: 24 V DC.
-
Rated Current: 4 A.
-
Standard Length: 800 mm (31.5 in).
-
Included Components: DIN rail, conductor insert, cover, and end caps.
-
Installation Benefit: Reduces wiring complexity by eliminating individual daisy-chain connections.
The UPR-03-S delivers the reliability and precision required for organized power distribution and fault signaling in modular industrial control systems.
