Pepperl+Fuchs VDM28-50-R-IO/73C/110/122 Laser Distance Sensor 50 m
- Regular price
- $747.00
- Sale price
- $747.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VDM28-50-R-IO/73C/110/122
Description
The Pepperl+Fuchs VDM28-50-R-IO/73C/110/122 is a laser distance sensor designed for non-contact distance measurement using a reflector. It uses Pulse Ranging Technology (PRT), supports measurement distances up to 50 m, and provides IO-Link communication alongside an analog output for industrial automation applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Pepperl+Fuchs |
| Category | Sensors & Transducers |
| Part Number | VDM28-50-R-IO/73C/110/122 |
| Subcategory | Laser Distance Sensors |
| Sensor Type | Reflector-based laser distance sensor |
| Measurement Range | 0.2–50 m |
| Measuring Method | Pulse Ranging Technology (PRT) |
| Reference Reflector | OFR-100/100 |
| Light Source | Modulated visible red laser |
| Wavelength | 660 nm |
| Laser Class | Class 2 |
| Operating Voltage | 10–30 V DC; 18–30 V DC in IO-Link mode |
| Communication Interface | IO-Link V1.0 |
| IO-Link Mode | COM2, 38.4 kbit/s |
| Analog Measurement Output | 4–20 mA |
| Switching Output | Push-pull, short-circuit and reverse-polarity protected |
| Maximum Switching Current | 100 mA |
| Switching Frequency | 50 Hz |
| Response Time | 10 ms |
| Absolute Accuracy | ±25 mm |
| Repeat Accuracy | Less than 5 mm |
| Connection | 4-pin M12 × 1 connector |
| Protection Rating | IP65 |
| Housing Material | ABS plastic |
| Dimensions (H × W × D) | 88 × 25.8 × 54.6 mm |
| Weight | 0.198 lb |
Information About VDM28-50-R-IO/73C/110/122
The VDM28-50-R-IO/73C/110/122 is a Pepperl+Fuchs distance sensor designed to measure the distance to a compatible reflector. It uses modulated visible red laser light with a wavelength of 660 nm and a Class 2 laser rating. The sensor operates from a 10–30 V DC supply and supports IO-Link communication, with a 4–20 mA analog measurement output and a configurable switching output. Its compact housing, M12 connector, and pulse-ranging measurement method make it suitable for industrial distance monitoring and positioning applications.
-
Measurement Range: Measures distances from 0.2 m to 50 m using a suitable reflector.
-
Measurement Technology: Uses Pulse Ranging Technology (PRT) for distance measurement.
-
Laser Source: Visible red laser with a 660 nm wavelength.
-
Laser Classification: Class 2 laser source.
-
Communication Interface: Supports IO-Link V1.0 with COM2 communication.
-
Analog Output: Provides a 4–20 mA measurement signal.
-
Switching Output: Push-pull output with short-circuit and reverse-polarity protection.
-
Environmental Protection: IP65-rated housing for industrial installation.
The VDM28-50-R-IO/73C/110/122 delivers the reliability and precision required for long-range distance measurement, material handling, and industrial positioning systems.
