Product Description P/N: PFXGP4601TAD
Description
The Schneider Electric PFXGP4601TAD is a 12.1" color touchscreen operator interface from the GP4000 series. Its vibrant TFT display and intuitive design make it ideal for managing and monitoring industrial processes effectively.
Technical Specifications
| Brand | Schneider Electric |
| Part Number | PFXGP4601TAD |
| Product Type | HMI (Human Machine Interface), Touchscreen, Touchpanel HMI |
| Series / Product Family | GP4000 HMI Series |
| Display Size | 12.1 Inch |
| Display Type | TFT Color LCD Display |
| Resolution | 800 x 600 Pixels (SVGA) |
| Backlight | White LED |
| Brightness Options | 16 Adjustable Brightness Levels |
| Touch Panel Resolution | 1024 x 1024 |
| Application Memory | 32 MB |
| Input Voltage | 24 VDC |
| Interface Ports & Specifications | Qty 2 Serial Ports (COM1 & COM2), Qty 2 USB (TYPE A & Mini-B), Qty 1 Ethernet, Qty 1 SD Card Slot |
| Safety Standards | UL, cUL, EAC, Class NK Approved |
Information About PFXGP4601TAD
The PFXGP4601TAD is a 12.1" operator interface from Pro-face. It has a high quality display and several other features that make it stand out among other interfaces. For example, the PFXGP4601TAD can support up to 4 protocol drivers at the same time, transfer applications 10 times faster than conventional interfaces, and draw less power than less energy-efficient devices.
Interface Features
The display of the PFXGP4601TAD is a high-quality TFT color LCD with an 800 by 600 SVGA resolution. This display is capable of producing up to 65,536 colors with no blink or 16,384 with blink. This unit's backlight is an energy-efficient white LED. The brightness and contrast of this model can be adjusted to 16 different levels each, either via the touch panel or the software. The touch panel of this unit is a 1024 by 1024 gridless resistive film panel. The software this unit uses is GP Pro EX, which is simple and easy to use while adding a host of features to make the PFXGP4601TAD more effective and convenient to use.
Power/Environmental Specifications
The PFXGP4601TAD is a DC24V-rated unit. It can handle a total voltage range of 19.2 to 28.8V. The power draw of this model is 17 W or less thanks to the energy-efficient LED. Operational temperatures should remain between 0°C and 55°C in order to ensure normal functionality and longevity of the device. In storage conditions, the unit can be exposed to temperatures between -20°C and 60°C without greatly risking the integrity of the internal parts.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
