PFXSP5B00 | Pro-face SP-5B00 Modular Box

The PFXSP5B00 operates within a surrounding air temperature range of 0 to 60 °C [32 to 140 °F], allowing it to function reliably in a wide array of operational conditions, from standard indoor environments to challenging industrial settings. The storage temperature ranges from -20 to +60 °C [-4 to 140 °F], providing protection during storage and ensuring the unit remains functional after being exposed to cooler or hotter conditions prior to installation or operation. These temperature specifications make the PFXSP5B00 highly adaptable for use in varied climates, including temperature-controlled environments or facilities with fluctuating temperatures.

The unit supports ambient humidity levels of 10 to 90 % RH, with a maximum wet bulb temperature of 39 °C [102.2 °F], ensuring reliable operation without condensation. This humidity tolerance extends to storage conditions, allowing the PFXSP5B00 to be stored in similarly humid environments without performance degradation. The dust tolerance of the PFXSP5B00 is 0.1 mg/m³ (10⁻⁷ oz/ft³) or less, which ensures the system is suitable for clean environments where non-conductive dust levels are low, further enhancing its reliability in a variety of operating conditions.

Designed for industrial use, the PFXSP5B00 is intended for Pollution Degree 2 environments, which means it is suitable for use in areas where only non-conductive pollution is present. This specification ensures safe and reliable operation in typical industrial environments where occasional condensation may occur but where more aggressive pollutants or corrosive substances are absent. The unit is also designed to operate free of corrosive gases, making it suitable for installation in environments where the presence of corrosive gases could damage sensitive electronic components.

With an air pressure tolerance ranging from 800 to 1,114 hPa, the PFXSP5B00 can operate effectively at altitudes up to 2,000 meters [6,561 ft.] above sea level, ensuring reliable performance even in elevated locations. This air pressure tolerance further adds to the versatility of the PFXSP5B00, allowing it to be deployed in various geographical regions and industrial facilities with different altitude requirements.

Connectivity is a key feature of the PFXSP5B00, providing multiple communication interfaces that allow seamless integration with other industrial systems and devices. The unit is equipped with two Ethernet interfaces (Ethernet I/F), allowing for high-speed communication with industrial networks and other control systems. These Ethernet ports provide the PFXSP5B00 with the ability to connect to larger, networked automation systems, facilitating data exchange and real-time communication across the network.

In addition to Ethernet connectivity, the PFXSP5B00 is equipped with two communication interfaces (COM I/F), which enhance its ability to interface with other devices, such as PLCs, sensors, and control modules. The inclusion of two USB A interfaces (USB A I/F) allows the connection of external devices, including USB memory sticks or additional peripherals, further extending the functionality and flexibility of the unit. The USB Mini interface (USB Mini I/F) offers additional connectivity for smaller devices, making the PFXSP5B00 a highly versatile solution for integrating various components and expanding system capabilities.

The PFXSP5B00 also features an SD card slot, providing an easy and efficient way to store and transfer data. This allows operators to back up system data, save operational parameters, or transfer configurations between systems quickly and easily. The SD card slot enhances the overall functionality of the unit, making it suitable for applications where data logging or transfer is essential for maintaining operational efficiency.

Running on a Real-Time Operating System (RTOS), the PFXSP5B00 offers precise control over time-sensitive industrial processes. The RTOS ensures that tasks are executed within specific time constraints, which is critical for many industrial automation applications where timing precision can directly impact performance and safety. The RTOS enables the PFXSP5B00 to manage multiple processes simultaneously, maintaining optimal performance even in complex systems.

The PFXSP5B00 also comes with 1 GB of on-board flash memory, providing sufficient storage for system files, configurations, and application data. This internal memory allows the unit to store essential data locally, reducing reliance on external storage devices and ensuring that critical data remains accessible even in the event of network interruptions or failures.

Overall, the Pro-face PFXSP5B00 modular box is a versatile and reliable solution for industrial automation. With its wide temperature and humidity tolerance, multiple connectivity options, pollution and dust resistance, and real-time operating system, it is well-suited for a variety of industrial environments. The PFXSP5B00 provides robust control and data management capabilities, ensuring optimal performance and reliability in demanding automation applications.
