Product Description P/N: PGA36120U44A

Description / Specifications

Description

The PGA36120U44A is a Circuit Breaker belonging to the PowerPacT P series, designed to safeguard electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers offer either a fixed long-time electronic trip unit, ET 1.0I, or Micrologic trip units, providing interchangeability in the field for enhanced flexibility.

This specific circuit breaker features a Micrologic Interchangeable Ammeter with a 6.0A trip unit and LSIG function. It includes an integral push-to-trip button in the cover for manual tripping.



Technical Specifications

Part #

PGA36120U44A

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Range

PowerPact

Product name

PowerPact P

Product or Component Type

Circuit Breaker

Device Application

Line

Rated Current

1200 A

Number of Poles

3P

Control Type

Toggle

Breaking Capacity Code

G

Rated Operational Voltage (Ue)

600 V AC 50/60 Hz UL 489

Network Frequency

50/60 Hz

Rated Impulse Withstand Voltage (Uimp)

8 kV IEC 60947-2

Trip Unit Technology

Electronic, ammeter, MicroLogic 6.0 A, LSIG

Continuous Current Rating

80 %

Rated Insulation Voltage (Ui)

750 V IEC 60947-2

Trip Unit Name

MicroLogic 6.0 A

AWG Gauge

4 x AWG 3/0...500 kcmil aluminium/copper

Mounting Mode

I-Line bracket

Mounting Support

Bracket

Electrical Connection

I-Line connection, line



Lugs, load

Terminal Identifier

AL1200P25K

Long Time Pick-Up Adjustment Range

0.4...1 x Ir

Mounting Height

9 in (228.60 mm)

Power Wire Stripping Length

1.18 in (30 mm)

Height

16.16 in (410.46 mm)

Width

8.27 in (210.06 mm)

Depth

8.05 in (204.47 mm)

Net Weight

32 lb(US) (14.51 kg)

Quantity per Set

1

Phase Connection

ABC

Circuit Breaker Application

HACR rated

IP Degree of Protection

Front cover IP40

Pollution Degree

3 IEC 60947-1

Ambient Air Temperature for Operation

-13…158 °F (-25…70 °C)

Ambient Air Temperature for Storage

-58…185 °F (-50…85 °C)





Information About PGA36120U44A


The PGA36120U44A is a Circuit Breaker belonging to the PowerPacT P series, designed specifically to safeguard electrical systems from potential damage resulting from overloads and short circuits. Featuring a robust construction, PowerPacT P-Frame circuit breakers are equipped with either a fixed long-time electronic trip unit, ET 1.0I, or Micrologic trip units, providing versatility in functionality.

One notable feature of the PGA36120U44A is its Micrologic Interchangeable Ammeter with a 6.0A trip unit and LSIG function, offering precise monitoring and protection capabilities. Additionally, all PowerPacT circuit breakers are outfitted with an integral push-to-trip button in the cover, enabling manual tripping when necessary.

Available in various configurations, including 2, 3, and 4-pole unit mounts, I-Line, or drawout constructions, PowerPacT P circuit breakers offer flexibility to suit different application requirements. This specific unit features I-Line terminations on the line side and mechanical lugs on the load side, ensuring ease of installation and reliable connectivity.
