PHPM-WBX-DV-WH | Lutron Power Module Phase Adapter White for Multi-Voltage Lighting Control
- Regular price
- $389.00
- Sale price
- $389.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: PHPM-WBX-DV-WH
Description
The Lutron PHPM-WBX-DV-WH is a phase-adaptive power module designed to provide dimming control for a wide range of lighting sources including incandescent, halogen, and low-voltage systems. It supports 3-wire fluorescent dimming and is suitable for both surface and recessed mounting. This module is ideal for indoor lighting applications requiring precise dim control.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Lutron |
| Category | Lighting Control |
| Part Number | PHPM-WBX-DV-WH |
| Subcategory | Power Modules |
| Voltage Rating | 120/277 V |
| Load Capacity | 16 A |
| Compatible Loads | Incandescent, Halogen, ELV, MLV, Neon |
| Dimming Type | Phase-Adaptive (leading/trailing edge) |
| Mounting | Surface or Recessed |
| Frequency Rating | 50 - 60 Hz |
| Operating Temp. | 0°C to 40°C |
| Standards | UL, RoHS, CSA, NOM, CIDET |
| Dimensions | 11 x 8.5 x 5.5 inches |
| Weight | 1.75 lbs |
Information About PHPM-WBX-DV-WH
The PHPM-WBX-DV-WH is part of Lutron’s reliable power module series built for seamless integration with advanced dimming systems. This unit supports multiple lighting technologies, including magnetic low-voltage, electronic low-voltage, and fluorescent lamps. Its phase-adaptive technology automatically chooses leading-edge or trailing-edge dimming for optimal performance. Compatible with both 120V and 277V inputs, it fits various commercial and residential lighting setups.
Key Features:
-
Phase-Adaptive Technology: Automatically selects between leading-edge and trailing-edge dimming modes for transformers.
-
Wide Compatibility: Supports incandescent, halogen, magnetic low-voltage, electronic low-voltage, neon, and fluorescent lighting.
-
High Load Capacity: Provides dim control for a full 16A load on a 3-wire fluorescent dimmer.
-
Multiple Module Control: Up to 3 power modules can be managed by a single dimmer for expanded control zones.
-
Voltage Support: Works with 120/277V inputs and is compatible with 220/240V non-CE systems requiring 120V control input.
-
Mounting Flexibility: Suitable for surface or recessed mounting applications.
-
System Integration: Compatible with Lutron GRAFIK Eye QS, GRAFIK Eye 3000 Series, LP, LCP, GP dimming panels, and HomeWorks systems.
-
Safety Standards: Certified UL, RoHS, CSA, NOM, and CIDET compliant for reliable operation.
The PHPM-WBX-DV-WH delivers the reliability and precision required for advanced lighting control in varied environments.
