Product Description P/N: PM135EH
Description
The PM135EH is the enhanced version of the PM135 series—a multi-functional, three-phase power meter tailored for utility substation automation and industrial SCADA systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Satec |
| Category | Electrical Measurement / Industrial Metering |
| Part Number | PM135EH |
| Subcategory | Multi-Functional 3-Phase Power & Energy Meter (Revenue & PQ) |
| Accuracy Class | IEC 62053-22 Class 0.5S (optional 0.2S) |
| Voltage Input | 0–690 V AC (direct) |
| Current Input | CT secondary: 1 A, 5 A, 40 mA HACS, RS5 |
| Harmonics | Up to 40th order, THD/TDD/K-Factor |
| TOU Billing | 8 tariffs, 4 seasons, 4 day types, multiple registers |
| Event/Data Logging | 48-day log, half-hourly writes, 100+ events |
| I/O Options | Up to 16 I/O with various modules |
| Communications | RS-485 standard; optional Ethernet, cellular, RS-232/422/485, Profibus, RF |
| Protocols | Modbus RTU/TCP, SATEC ASCII, DNP3, IEC 60870-5-101/104 |
| Display | Backlit LCD + LED load bar |
| Power Supply | 85–265 V AC / 88–290 V DC |
| Mounting | Square 92 × 92 mm or Round 4″ panel cutout |
| Dimensions | 114 × 114 × 109 mm |
| Weight | 0.7 kg (1.5 lb) |
Information About PM135EH
The Satec PM135EH is a multi-functional three-phase power meter designed for revenue-grade metering, advanced power quality monitoring, and industrial automation applications. As the enhanced energy and harmonic version of the PM135 series, it offers high-accuracy measurement, comprehensive harmonic analysis, and flexible communication options for utility substations, SCADA systems, and energy management solutions.
Key Features:
- Based On: Satec PM135 platform with extended energy and harmonic analysis capabilities.
- Measurement Range: Voltage, current, active/reactive/apparent power, energy (4-quadrant), power factor, frequency, and voltage/current unbalance.
- Power Quality: Harmonic analysis up to the 40th order with THD, TDD, and K-Factor.
- Billing Functions: Time-of-Use metering with multiple tariffs, seasons, and day types.
- Logging Functions: 48 days of TOU logs, half-hourly trending, and 100+ event records.
- Control Capability: Embedded PLC with 16 programmable setpoints and relay control.
- Communication: Standard RS-485 with Modbus RTU; optional Ethernet, Profibus, cellular, RS-232/422; supports Modbus TCP, DNP3, and IEC 60870.
- I/O Options: Expandable digital and analog inputs/outputs up to 16 points.
- Display: Backlit LCD with LED load bar for real-time status.
- Mounting: Panel mount—square (92 × 92 mm) or round (4″) cutouts.
- Weight: ~0.7 kg.
The Satec PM135EH delivers precise metering, robust power quality diagnostics, and scalable connectivity in a compact, modular format—making it a reliable choice for permanent installations requiring both accurate energy measurement and advanced electrical network monitoring.
