ProSoft Technology PS-QS-2010-F 250-Point Universal QuickServer Communication Gateway
- Regular price
- $1,829.00
- Sale price
- $1,829.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: PS-QS-2010-F
Description
The ProSoft Technology PS-QS-2010-F is a Universal QuickServer communication gateway designed to exchange data between building automation systems and industrial control networks. It supports up to 250 application data points and provides Ethernet and serial connectivity for integrating BACnet, Metasys N2, EtherNet/IP, and Modbus-based equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | ProSoft Technology |
| Category | PLCs/Machine Control |
| Part Number | PS-QS-2010-F |
| Subcategory | PLC Module/Rack |
| Product Type | Universal QuickServer Gateway |
| Application Data Capacity | Up to 250 points |
| Ethernet Interface | 10/100 RJ45 |
| Serial Ports | 2 |
| Serial Interface 1 | RS-485/RS-232 |
| Serial Interface 2 | RS-485 |
| Power Requirement | 9 to 30 volts alternating current or direct current |
| Current Draw | 250 milliamperes at 12 volts |
| Operating Temperature | -4 to 158 degrees Fahrenheit (-20 to +70 degrees Celsius) |
| Relative Humidity | 10% to 95%, non-condensing |
| Dimensions | 4 × 1.1 × 2.7 inches (10.16 × 2.8 × 6.8 centimeters) |
| Mounting | DIN rail |
| Product Status | Discontinued by manufacturer |
| Weight | 0.20 kg |
Information About PS-QS-2010-F
The PS-QS-2010-F is a 250-point model from the ProSoft Technology Universal QuickServer gateway family. Its compact enclosure includes one 10/100 Ethernet RJ45 connection and two serial ports, consisting of one RS-485/RS-232 interface and one RS-485 interface. The gateway supports integration between building automation protocols such as BACnet MS/TP, BACnet/IP, and Johnson Controls Metasys N2 and industrial protocols including EtherNet/IP, Modbus RTU, and Modbus TCP/IP. Its multi-configuration capability and included DIN rail mounting support installation in building automation, heating, ventilation and air conditioning, energy management, and industrial control panels.
Key Features:
- 250-Point Capacity: Supports up to 250 application data points for communication between connected automation networks.
- Building and Industrial Integration: Links building automation networks with industrial control equipment through protocol conversion.
- Ethernet Connectivity: Provides a 10/100 RJ45 Ethernet interface for Ethernet-based network communications.
- Dual Serial Interfaces: Includes one RS-485/RS-232 serial port and one additional RS-485 serial port.
- Multiple Protocol Support: Supports configurations involving BACnet MS/TP, BACnet/IP, Metasys N2, EtherNet/IP, Modbus RTU, and Modbus TCP/IP.
- Flexible Power Input: Operates from a 9 to 30 volt alternating current or direct current supply.
- Wide Operating Temperature: Rated for operation from -4 to 158 degrees Fahrenheit (-20 to +70 degrees Celsius).
- DIN Rail Installation: Supplied with DIN rail mounting hardware for installation inside automation and control enclosures.
The PS-QS-2010-F delivers the reliability and precision required for protocol conversion and data exchange between building automation and industrial control networks.
