Product Description P/N: PSG240E
Description
The PSG240E is a low-profile power supply manufactured by Eaton under the PSL series. With a power rating of 240 watts, it operates on single-phase electrical systems with an input voltage range of 100-240 volts. The output voltage is stabilized at 24 volts direct current (Vdc) with a tolerance of ±2%. The input current rating is 2.9 amperes (A), while the output current capacity is 10A. It accommodates input frequencies ranging from 47 to 63 Hertz (Hz) and input voltages between 85 and 264 volts alternating current (VAC) or 120 to 375 volts direct current (VDC).
Technical Specifications
|
Brand |
EATON |
|
Type |
1-ph Low Profile |
|
Series |
PSG |
|
Input Voltage |
100 to 240 VAC, 85 to 264 VAC, 100 to 375 VDC |
|
Output Voltage |
24 VDC |
|
Power Rating |
240 W |
|
Amperage Rating |
2.9 A |
|
Frequency Rating |
47 to 63 Hz |
|
Mounting Type |
DIN Rail |
|
Case Material |
Aluminum |
Information About PSG240E
The PSG240E is a low-profile power supply unit manufactured by Eaton as part of their PSL series. With a power output rating of 240 watts, it is designed for single-phase electrical systems, accommodating input voltages ranging from 100 to 240 volts. The unit delivers a stabilized output voltage of 24 volts direct current (Vdc) with a variance tolerance of ±2%.
The PSG240E is engineered to handle an input current of 2.9 amperes (A) and can deliver an output current of up to 10A. It operates within a frequency range of 47 to 63 Hertz (Hz). It accepts input voltages spanning from 85 to 264 volts alternating current (VAC) or 120 to 375 volts direct current (VDC), providing flexibility in its compatibility with various power systems.
Encased in an aluminum enclosure, the PSG240E ensures durability and protection against environmental factors. Its heavy-duty screw terminals facilitate secure and reliable connections, enhancing operational safety and stability.
Manufacturer information
Eaton Corporation is a multinational power management company offering a diverse range of electrical, hydraulic, and aerospace solutions. Known for innovation, Eaton serves customers in various industries worldwide.
