PX2AF1XX200PSAAX | Honeywell PX2 Series Pressure Sensor 200 PSI Sealed Gauge, 0.5–4.5 V Analog Output
- Regular price
- $369.00
- Sale price
- $369.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: PX2AF1XX200PSAAX
Description
The Honeywell PX2AF1XX200PSAAX is a high-accuracy industrial pressure sensor designed for sealed gauge measurement up to 200 PSI. Operating on 5 VDC with a 0.5–4.5 V analog output, this PX2 Series sensor provides ±0.25% accuracy, temperature compensation, and durable construction for reliable performance in demanding automation and control environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Industrial Sensors |
| Part Number | PX2AF1XX200PSAAX |
| Subcategory | Pressure Sensors |
| Series | PX2 Series |
| Product Type | Industrial transducer, pressure sensor |
| Pressure Type | Sealed gauge |
| Operating Pressure Range | 0–200 PSI (0–1378.95 kPa) |
| Maximum Pressure | 750 PSI (5171.07 kPa) |
| Accuracy | ±0.25% full scale |
| Output Type | Amplified analog voltage |
| Output Range | 0.5–4.5 VDC |
| Supply Voltage | 4.75–5.25 VDC |
| Supply Current | 5 mA typical |
| Port Size | 7/16" UNF Schrader (female) |
| Port Style | Threaded connection |
| Pressure Medium | Clean air, non-corrosive gases, compatible fluids |
| Termination Style | Electrical connector |
| Temperature Compensation | Yes (factory calibrated and compensated) |
| Operating Temperature Range | -40°C to +125°C (-40°F to +257°F) |
| Housing Material | Stainless steel and reinforced polymer |
| Electrical Isolation | Integrated amplifier and EMI/RFI shielding |
| Output Signal Type | Ratiometric with supply voltage |
| Response Time | <1 ms typical |
| Mounting | Inline or manifold compatible |
| Applications | Industrial automation, HVAC, hydraulic systems, pneumatic equipment |
| Certifications | RoHS compliant, CE approved |
| Dimensions | 63.4 mm (L) × 21.5 mm (H) |
| Weight | 1.00 lbs (approx. 0.45 kg) |
Information About PX2AF1XX200PSAAX
The Honeywell PX2AF1XX200PSAAX belongs to the PX2 Series of amplified pressure sensors, designed to deliver accurate and stable analog output in harsh industrial environments. This sealed gauge transducer measures pressures up to 200 PSI with an impressive ±0.25% full-scale accuracy. Operating on a 5 VDC supply, it outputs a ratiometric analog signal between 0.5 V and 4.5 V for straightforward integration with control systems and PLCs. The sensor features internal temperature compensation, minimizing drift and error over a wide operating range of -40°C to +125°C. Its 7/16"-20 UNF threaded port ensures secure and leak-resistant installation in hydraulic, pneumatic, or automation systems. Built with rugged materials and EMI/RFI protection, the PX2AF1XX200PSAAX provides long-term durability and reliability in high-vibration and demanding applications.
Key Features:
- High-Precision Measurement: Provides ±0.25% full-scale accuracy for precise monitoring of process or system pressure.
- Sealed Gauge Configuration: Measures pressure relative to an internal reference, ideal for sealed environments and consistent performance.
- Wide Operating Range: Handles pressures up to 200 PSI (750 PSI maximum) with consistent accuracy across temperature extremes.
- Analog Output Signal: Amplified 0.5–4.5 VDC output ensures easy interfacing with standard industrial control systems.
- Stable 5 VDC Operation: Operates from a regulated 4.75–5.25 VDC power supply with minimal current draw.
- Temperature Compensation: Factory-calibrated for stable readings across -40°C to +125°C without user recalibration.
- Durable Construction: Corrosion-resistant housing and sealed electrical connector withstand harsh industrial environments.
- Fast Response Time: Rapid analog signal response (<1 ms) suitable for dynamic pressure monitoring applications.
- Threaded Port Design: Standard 7/16"-20 UNF Schrader port provides secure, leak-free installation.
- Industrial Compatibility: Designed for use in automation, fluid control, and HVAC systems requiring robust and accurate pressure feedback.
The PX2AF1XX200PSAAX delivers the reliability and precision required for industrial pressure measurement, ensuring stable and accurate operation across demanding environmental and process conditions.
