Q2100HH | Siemens 100A 2-Pole Molded Case Circuit Breaker 120/240V 65kA
- Regular price
- $252.00
- Sale price
- $252.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: Q2100HH
Description
The Siemens Q2100HH is a 2-pole molded case circuit breaker designed to provide dependable protection for residential, commercial, and light industrial electrical systems. Rated at 100 amps and 120/240 VAC, this breaker ensures efficient overload and short-circuit protection with a high interrupting capacity of 65kA@240V. The Q2100HH combines durable construction with Siemens’ reliable thermal magnetic trip technology for long-term performance.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Circuit Breaker |
| Part Number | Q2100HH |
| Subcategory | Molded Case |
| Series | Q Series |
| Type | HQP |
| Amperage Rating | 100 A |
| Voltage Rating | 120/240 VAC |
| Poles | 2 |
| Phase | Single Phase |
| Interrupting Rating | 65kA@240V |
| Trip Function | LI – Long-Time and Instantaneous |
| Protection Type | Thermal Magnetic |
| Connection Type | Plug-In |
| Mounting Type | Bolt-On |
| Wire Size Range | #8 to 2/0 AWG (Al/Cu) |
| Frame Type | Q Frame |
| Standards | UL Listed |
| Country of Origin | Mexico |
| Dimensions | 2.756 x 2.756 x 1.969 in |
| Weight | 0.68 lbs |
Information About Q2100HH
The Q2100HH is part of the Siemens Q Series of molded case circuit breakers, known for their compact size and high interrupting capabilities. Built with thermal magnetic trip technology, it offers both long-time and instantaneous protection against overloads and short circuits. Designed for plug-in or bolt-on mounting, the breaker is compatible with Siemens load centers and panelboards. Its robust 2-pole configuration supports single-phase applications, making it suitable for both residential and commercial electrical installations.
Key Features:
- High Interrupting Capacity: Rated at 65kA@240V for enhanced fault protection.
- Thermal Magnetic Trip Unit: Provides precise overload and short-circuit protection.
- Compact 2-Pole Design: Ideal for 120/240 VAC single-phase systems.
- Plug-In Mounting: Simplifies installation in Siemens load centers and panels.
- Durable Frame Construction: Ensures long operational life under demanding conditions.
- UL Listed: Certified for safety and compliance with industry standards.
- Wide Wire Range: Accepts #8 to 2/0 AWG aluminum or copper conductors.
- Reliable Performance: Engineered for consistent operation in residential and commercial environments.
The Q2100HH delivers the reliability and precision required for dependable circuit protection in modern electrical systems.
