QO120PAFGF | Schneider Electric Mini Circuit Breaker
- Regular price
- $77.00
- Sale price
- $77.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: QO120PAFGF
Description
The QO120PAFGF is a mini circuit breaker from the QO series, designed to provide reliable overcurrent protection and switching for both AC and DC systems. Featuring a single pole configuration, this breaker is rated at 20A for 120VAC applications. With a robust construction, it offers a breaking capacity of 10kA to ensure efficient performance.
Equipped with a thermal magnetic mechanism, the QO120PAFGF ensures quick make and quick break action, facilitated by an over-center, trip-free toggle mechanism. Additionally, it includes positive handle indication for enhanced operational safety. The VisiTrip trip indication feature provides a visual cue in case of tripping, indicating that the circuit breaker has interrupted the circuit.
Technical Specifications
|
Part # |
QO120PAFGF |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Product |
Miniature circuit-breaker |
|
Range |
QO |
|
Current Rating |
20 A |
|
Voltage Rating |
120 V AC |
|
Mounting Type |
Plug-in |
|
Number of Poles |
1P |
|
Ratings |
HACR rated |
|
Electrical Connection |
Pressure plate |
|
Connections Terminals |
Plug-on neutral |
|
Interrupt Rating |
10 kA 120 V AC |
|
Number of Panel Spaces |
1 |
|
Wire Size |
AWG 14...AWG 8 copper or aluminium |
|
Tightening Torque |
35.40 lbf.in (4 N.m) |
|
Height |
2.72 in (69.08 mm) |
|
Width |
0.75 in (19.05 mm) |
|
Depth |
4.10 in (104.14 mm) |
|
Net Weight |
0.35 lb(US) (0.159 kg) |
Information About QO120PAFGF
The QO and QOB thermal magnetic circuit breakers, available in one, two, and three-pole configurations, offer overcurrent protection and switching capabilities for both AC and DC systems. Featuring an over-center, trip-free toggle mechanism, these circuit breakers ensure quick make and break actions with positive handle indication. Additionally, they are equipped with VisiTrip trip indication, providing a visual alert when the circuit breaker trips and interrupts the circuit. Various factory-installed accessories, including shunt trips, auxiliary switches, and alarm switches, are available to enhance functionality.
The QO120PAFGF is a one-pole QO circuit breaker rated for 20A at 120VAC. With a breaking capacity of 10kA, it ensures reliable protection against overcurrents. Designed for plug-in mounting, this circuit breaker features a dual-function capability with plug-on neutral. This innovative feature provides a combination of arc fault and ground fault protection, enhancing safety measures in electrical systems.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
Description
The QO120PAFGF is a mini circuit breaker from the QO series, designed to provide reliable overcurrent protection and switching for both AC and DC systems. Featuring a single pole configuration, this breaker is rated at 20A for 120VAC applications. With a robust construction, it offers a breaking capacity of 10kA to ensure efficient performance.
Equipped with a thermal magnetic mechanism, the QO120PAFGF ensures quick make and quick break action, facilitated by an over-center, trip-free toggle mechanism. Additionally, it includes positive handle indication for enhanced operational safety. The VisiTrip trip indication feature provides a visual cue in case of tripping, indicating that the circuit breaker has interrupted the circuit.
