QOB3601021 | Schneider Electric Mini Circuit Breaker
- Regular price
- $774.00
- Sale price
- $774.00
- Regular price
-
Couldn't load pickup availability
Do you need more quantity?
Product Description P/N: QOB3601021
Description
The QOB3601021 mini circuit breaker, part of the QO series by Schneider Electric, offers robust overcurrent protection and switching capabilities for both AC and DC systems. Featuring a thermal magnetic mechanism, these circuit breakers utilize an over center, trip-free toggle mechanism with quick make, quick break action and positive handle indication. The VisiTrip trip indication provides clear visual feedback when the breaker has tripped and interrupted the circuit.
Technical Specifications
|
Part # |
QOB3601021 |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Product |
Miniature circuit-breaker |
|
Range |
QO |
|
Current Rating |
60 A |
|
Mounting Type |
Bolt-on |
|
Number of Poles |
3P |
|
Circuit Breaker Type |
Standard |
|
Ratings |
HACR rated |
|
Options |
Shunt trip 120/208/240 V AC |
|
Number of Panel Spaces |
4 |
|
Wire Size |
AWG 8...AWG 2 copper or aluminium |
|
Tightening Torque |
44.25 lbf.in (5 N.m) |
|
Height |
3.11 in (79 mm) |
|
Width |
2.99 in (76 mm) |
|
Depth |
2.91 in (74 mm) |
Information About QOB3601021
The QOB3601021 is a three-pole miniature circuit breaker from the QO series by Schneider Electric, designed to provide overcurrent protection and switching capabilities for AC and DC systems. These thermal magnetic circuit breakers feature an over-center, trip-free toggle mechanism with quick make, quick break action, and positive handle indication for ease of operation. They are equipped with VisiTrip trip indication, offering a visual signal when the breaker has tripped and interrupted the circuit.
This QO circuit breaker model supports a wide range of applications and is complemented by a variety of factory-installed accessories including shunt trips, auxiliary switches, and alarm switches, enhancing its functionality in diverse electrical setups.
Key specifications of the QOB3601021 include a current rating of 60A at 120/240VAC and a breaking capacity of 10kA. It features bolt-on mounting for secure installation and includes an AC shunt trip mechanism for added versatility in circuit control.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
IQElectro 2 Year Warranty
IQElectro offers a 2-Year Warranty on all our products. This complimentary two-year warranty ensures that every purchase from IQElectro is a secure investment in the future of your company.Warranty Terms
IQElectro is not an authorized distributor.
