QOM2200VH | Schneider Electric Main breaker
QOM2200VH | Schneider Electric Main breaker

QOM2200VH | Schneider Electric Main breaker

Part #: QOM2200VH Manufactured by: Schneider Electric
Regular price
$139.00
Sale price
$139.00
Regular price
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The QOM2200VH is a 2-pole main breaker from the QO series by Eaton, designed for applications requiring overcurrent protec...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: QOM2200VH
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Schneider Electric
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
QOM2200VH | Schneider Electric Main breaker
    QOM2200VH | Schneider Electric Main breaker
QOM2200VH | Schneider Electric Main breaker

Product Description P/N: QOM2200VH

Description / Specifications

Description

The QOM2200VH is a main breaker from the QO series by Eaton. It is a two-pole thermal magnetic circuit breaker designed to provide overcurrent protection and switching on both AC and DC systems. Featuring an over-center, trip-free toggle mechanism with quick make, quick break action and positive handle indication, these circuit breakers offer reliable operation.

Equipped with VisiTrip trip indication, they provide a visual indication when the circuit breaker has tripped and interrupted the circuit. Additionally, a wide range of features and factory-installed accessories such as shunt trips, auxiliary switches, and alarm switches are available.



Technical Specifications

Part #

QOM2200VH

Category

Circuit Breaker

Subcategory

Load Center Circuit Breaker

Product Range

Miniature circuit-breaker

Current Rating

200 A

Voltage Rating

120/240 V AC, 120 V AC

Mounting Type

Bolt-on

Number of Poles

2P

Circuit Breaker Type

Standard

Electrical Connection

Lugs

Frame Size

QOM2

Wire Size

AWG 4...300 kcmil aluminium/copper

Tightening Torque

53.10 lbf.in (6 N.m) 0.01…0.10 in² (4…65 mm²) (AWG 12...AWG 2/0)

Height

5.59 in (142 mm)

Width

3.58 in (91 mm)

Depth

5.08 in (129 mm)

Net Weight

2.57 lb(US) (1.165 kg)

Load Center Type

Main breaker

Number of Phases

1 phase

Certifications

UL Listed, CSA

Ambient Rating

104 °F (40 °C)



Information About QOM2200VH

The QOM2200VH is a main breaker manufactured by Eaton, belonging to the QO series, designed to provide overcurrent protection and switching for both AC and DC systems. It is a 2-pole thermal magnetic circuit breaker with a rating of 200A at 120/240VAC.

These circuit breakers feature an over-center, trip-free toggle mechanism, ensuring quick make and quick break action, along with a positive handle indication for ease of use. Additionally, they incorporate VisiTrip trip indication, offering a visual cue when the circuit breaker has tripped and interrupted the circuit.

Eaton provides a comprehensive range of features and factory-installed accessories for these breakers, including shunt trips, auxiliary switches, and alarm switches, catering to various application needs.

The QOM2200VH main breaker offers a breaking capacity of 22kA and utilizes bolt-on mounting for secure installation. With a compact 3/4 inch width design, these QO breakers minimize the system footprint, making them suitable for installations with space constraints.



Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
