QOXD120 | Square D 20A 1-Pole 240V QO Plug-On Molded Case Circuit Breaker
- Regular price
- $65.00
- Sale price
- $65.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: QOXD120
Description
The Square D QOXD120 is a 20-amp, 1-pole molded case circuit breaker designed for dependable overcurrent protection in AC distribution systems. Operating at 240 VAC, it uses a thermal-magnetic trip mechanism to safeguard circuits from overload and fault conditions. Built within the QO series, the QOXD120 provides reliable switching performance in residential, commercial, and light industrial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | QOXD120 |
| Subcategory | Molded Case Circuit Breaker 20 AMP |
| Manufacturer | Schneider Electric |
| Poles | 1 |
| Amperage Rating | 20A |
| Voltage Rating | 240 VAC |
| Frequency | 50/60 Hz |
| Breaking Capacity | 3 kA |
| Series / Type | QO Series |
| Mounting Style | Plug-On |
| Trip Type | Thermal-Magnetic |
| Trip Indicator | VisiTrip visual trip indication |
| Toggle Mechanism | Over-center, trip-free |
| Certifications | UL Listed (E84967), CSA Certified |
| Application | Residential, commercial, and light industrial AC systems |
| Protection Functions | Overload and short-circuit protection |
Information About QOXD120
The QOXD120 is part of the Square D QO family, a series known for compact design and precise thermal-magnetic operation. It features a molded case construction with an over-center, trip-free toggle mechanism engineered for quick make/quick break functionality. The breaker integrates easily into compatible QO load centers using its plug-on mounting system. Designed for single-pole applications at 20 amps, it incorporates VisiTrip indication and supports stable performance across 240V AC systems commonly found in commercial and residential installations.
Key Features
- 20A single-pole protection: Ideal for branch circuit overcurrent control.
- Thermal-magnetic trip unit: Ensures accurate overload and short-circuit response.
- QO Series design: Built for compatibility with Square D QO load centers.
- VisiTrip indicator: Provides visual confirmation of breaker trip status.
- Quick make/quick break toggle: Supports reliable switching action and safety.
- Plug-on mounting: Enables fast installation and secure panel connection.
- 240 VAC operation: Suitable for AC distribution circuits requiring single-pole protection.
- UL and CSA certifications: Meets industry compliance and safety standards.
The QOXD120 delivers the reliability and precision required for dependable branch-circuit protection in AC distribution systems.
