QPH2D100S2P | GE Fanuc QuickPanel Touch Screen
- Regular price
- $5,277.00
- Sale price
- $5,277.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: QPH2D100S2P
Description
The GE Fanuc QPH2D100S2P is a compact QuickPanel handheld HMI designed for basic monitoring and control tasks in industrial automation systems. It features a 5.7-inch color STN touchscreen, operates on 24 V DC power, and supports configuration using QuickDesigner software.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | GE Fanuc |
| Category | HMI / MMI / OIT |
| Part Number | QPH2D100S2P |
| Subcategory | Operator Interface |
| Series | QuickPanel Hand Held |
| Screen Size | 5.7 in. |
| LCD Type | STN Color Display |
| Input Voltage | 24 V DC |
| NEMA Rating | Type 4X / 12, IP65 |
| Software Version | QuickDesigner v3.7 |
| Communication Ports | 2 Serial I/O ports |
| Cooling Method | Natural air convection |
| Mounting Style | Handheld |
| Unit Weight | 1.5 lbs (0.68 kg) |
| Unit Dimensions (W×H×D) | 6.71 × 5.43 × 3.44 in. |
Information About QPH2D100S2P
The QPH2D100S2P is part of GE Fanuc’s QuickPanel handheld HMI family developed for portable and space-constrained automation applications. It is built with a compact enclosure and a color touchscreen optimized for operator interaction and basic process visualization. The unit includes onboard serial communication ports and external function keys to simplify navigation and control. It is typically used in applications where portability, simple configuration, and localized machine interaction are required rather than full-scale system integration.
Key Features
- 5.7-Inch Color Touchscreen: Provides clear visualization using an STN LCD suitable for basic industrial HMI tasks.
- QuickPanel Handheld Design: Compact and lightweight form factor supports portable operation and easy handling.
- QuickDesigner Software Support: Configurable using QuickDesigner version 3.7 for screen creation and logic setup.
- 24 V DC Power Input: Compatible with standard industrial control power systems.
- Serial Communication Ports: Includes two serial I/O ports for basic controller connectivity and data exchange.
- Function Keys on Housing: External keys enable quick access to commonly used operations and navigation functions.
- Rugged Industrial Enclosure: Rated NEMA Type 4X/12 and IP65 for protection in industrial environments.
The QPH2D100S2P delivers the reliability and precision required for portable operator interaction and basic process control in industrial automation environments.
