QSGR-3P | Lutron GRAFIK Eye QS 3-Zone Main Unit, Wired Light/Shade Controller, 120–240V, Non-RF
- Regular price
- $889.00
- Sale price
- $889.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: QSGR-3P
Description
The Lutron QSGR-3P is a wired lighting and shade control unit from the GRAFIK Eye QS series, designed for managing three independent zones. This model supports voltage inputs from 120 to 240 VAC and features intuitive push-button scene recall. The unit integrates an astronomic timeclock, supports occupancy sensors, and communicates across the QS link for full-system synchronization. Its sleek design mounts on the surface, with faceplates sold separately.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Lighting Control Systems
|
| Part Number | QSGR-3P |
| Subcategory | Scene Controllers |
| Series | GRAFIK Eye QS |
| Voltage Range | 120–127V / 220–240V |
| Number of Zones | 3 |
| Wattage Capacity | 800W per channel / 2000W total |
| Load Types Supported | CFL, Incandescent, Halogen, MLV, Fluorescent |
| Mounting Type | Surface mount |
| Dimensions (W x H x D) | 9.38" x 4.69" x 2.38" |
| Scene Presets | 4 local scenes + 12 via QS devices |
| Timeclock | Built-in astronomic |
| Infrared Receiver | Integrated + external input |
| Shade Control | Optional buttons (addable post-installation) |
| Sensor Integration | One occupancy sensor input with 24V power |
| Communication Protocol | QS link |
| Operating Temperature | 0°C to 40°C |
| Certifications | UL, CSA, NOM, CEC |
| Weight | 0.1 lb |
Information About QSGR-3P
The QSGR-3P is part of Lutron’s GRAFIK Eye QS series and is a triac-based, non-RF controller designed for precise multi-zone lighting and shading automation. With a maximum load of 800 W per channel and 2000 W total, it is compatible with a wide range of lighting types including CFL, incandescent, halogen, magnetic low-voltage, and fluorescent. It includes a built-in IR receiver, astronomic timeclock, and direct integration with QS components such as SeeTouch wallstations and Quantum systems. This model is surface-mounted and suitable for both residential and commercial lighting projects requiring high adaptability.
Key Features:
- Three-Zone Base Unit: Provides independent control of three lighting zones via intuitive push-buttons.
- Scene Recall: Allows quick access to four local preset scenes and up to twelve additional scenes through QS devices.
- Astronomic Timeclock: Built-in scheduling based on sunrise and sunset for dynamic lighting control.
- Integrated Shade Support: Optional shade control buttons allow unified light and shade management.
- System Compatibility: Fully integrates with Lutron QS systems, including Quantum.
- IR and External IR Input: Supports infrared remote operation and external IR connections.
- Occupancy Sensor Input: One dedicated input with 24V power support for energy efficiency.
- Compliance and Safety: UL, CSA, NOM, and CEC (Title 24) certified.
The QSGR-3P delivers the reliability and flexibility required for advanced lighting and shading scenes in professional environments.
