R7023B1003 | Honeywell Flame Control
- Regular price
- $1,015.00
- Sale price
- $1,015.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: R7023B1003
Description
The Honeywell R7023B1003 is a solid-state flame safeguard primary burner control designed for commercial and industrial gas, oil, or combination-fired burner systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
Flame Safety Products
|
| Part Number | R7023B1003 |
| Subcategory | Flame Safety Accessory |
| Voltage | 120 VAC |
| Frequency | 50/60 Hz |
| Switching Type | 2 SPDT (Single-Pole, Double-Throw) |
| Compatible Base | Q270 Series Base |
| Flame Response Time | 3 seconds |
| Weight | 1.33 lbs |
Information About R7023B1003
The R7023B1003 is a solid-state flame safeguard control from Honeywell, designed for dependable burner management in commercial and industrial gas, oil, or combination-fired systems. Part of Honeywell’s flame safety product line, this primary burner control module is engineered for non-recycling applications where flame verification, burner sequencing, and safe shutdown are critical. Though discontinued, it remains a trusted choice in legacy systems, valued for its straightforward integration, compatibility with Q270 bases, and secure flame detection using rectification or UV sensing.
Key Features:
- Reliable Flame Supervision: Monitors burner flame presence using rectification flame rods or self-checking UV sensors, ensuring safe ignition and immediate response to flame failure.
- Manual Reset Safety: In the event of flame loss, the R7023B1003 initiates a lockout requiring manual reset, providing NFPA-compliant safety assurance for high-risk burner environments.
- Flexible Switching Control: Equipped with two SPDT (Single Pole, Double Throw) relay outputs, allowing versatile integration with actuators, alarm circuits, and control panels.
- Standard Voltage Operation: Operates at 120 VAC, 50/60 Hz—compatible with standard electrical systems in industrial and commercial boiler and furnace installations.
- Fast Flame Response: Features a flame failure response time of approximately 3 seconds, minimizing risk and protecting combustion equipment from unsafe operating conditions.
- Panel Mounting & System Integration: Designed for use with Honeywell’s Q270 series mounting bases, streamlining installation and facilitating easy replacement in existing burner control panels.
- Legacy Compatibility: Though discontinued by the manufacturer, the R7023B1003 continues to be available through surplus and remanufactured sources, maintaining support for long-established safety control installations.
The R7023B1003 offers a dependable flame safeguard solution for burner control systems that prioritize safety and system integrity. Its straightforward functionality, fast response, and compatibility with established Honeywell bases make it a practical option for maintaining critical operations—even in aging infrastructures that require continued serviceability.
