R7D-AP01H | Omron 100 W Servo Drive 200 VAC Single-Phase
- Regular price
- $766.00
- Sale price
- $766.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: R7D-AP01H
Description
The Omron R7D-AP01H is a 100 W servo driver from the R7 series, built for single-phase 200 VAC systems and designed to drive SmartStep A Series servo motors. Utilizing PWM control with IGBT technology, it supports precise pulse input control and operates within a compact IP20-rated chassis.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Motion Control |
| Part Number | R7D-AP01H |
| Subcategory | Servo Drives |
| Series | R7 |
| Voltage - Supply | 200 VAC (single-phase) |
| Voltage - Load | 200 V |
| DC Control Voltage | 24 VDC |
| Input Type | Pulse Input |
| Output Current | 0.89 A |
| Input Current | 2 A |
| Rated Power Output | 100 W |
| Control Method | PWM with IGBT |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail / Chassis Mount |
| Operating Temperature | 0°C to 55°C |
| Interface | Serial |
| Number of Motors Supported | 1 |
| Certifications | UL, cUL |
| For Use With | SmartStep A Series |
| Weight | 1.8 lbs (816.5 g) |
Information About R7D-AP01H
The R7D-AP01H is a servo drive module from Omron’s R7 series, optimized for small-scale automation tasks requiring high-speed, accurate motor control. Designed for use with SmartStep A Series motors, it supports single-phase 200 VAC input and outputs up to 0.89 A, delivering up to 100 W of power. The unit employs a pulse-width modulation (PWM) control method using an IGBT switching element, ensuring efficient and smooth motor operation. Compatible with DIN rail or chassis mounting, the R7D-AP01H integrates into control panels with minimal footprint and supports pulse input interfacing for position or speed control.
Key Features:
-
PWM Control with IGBT Switching: Ensures stable and responsive motor control using high-efficiency pulse-width modulation.
-
Pulse Input Interface: Accepts pulse signals for accurate positioning and speed regulation in servo applications.
-
Compact Single-Phase Design: Operates with 200 VAC single-phase power input and supports small motor loads up to 100 W.
-
Versatile Mounting Options: Can be mounted on DIN rail or directly on chassis to suit different panel configurations.
-
IP20 Protection Rating: Protected against solid objects over 12.5 mm, suitable for enclosed cabinet installations.
-
Wide Operating Temperature: Functions reliably in environments ranging from 0°C to 55°C.
-
Agency Approvals: Certified by UL and cUL for compliance with international safety standards.
-
Compact & Lightweight: Weighs only 1.8 lbs, facilitating easy installation and handling in space-constrained applications.
The R7D-AP01H delivers the reliability and precision required for accurate, space-efficient motion control in industrial automation systems.
