RP-1002 | Notifier Agent Releasing Control Panel
- Regular price
- $1,392.00
- Sale price
- $1,392.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: RP-1002
Description
The Notifier RP-1002 is a UL-listed agent releasing control panel designed to operate clean agent fire suppression systems. It features dual-zone detection, cross-zone logic, programmable delays, and advanced safety supervision.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Notifier |
| Category |
Fire Safety
|
| Part Number | RP-1002 |
| Subcategory | Fire Alarm Control |
| Power Input | 120 VAC, 60 Hz, 1.2 A (optional 230 VAC, 50 Hz) |
| Initiating Circuits | Style B (Class B) / Style D (Class A) |
| Notification Circuits | Style Y/Z, up to 1.5 A per circuit |
| Releasing Circuits | Style Y, up to 1.5 A |
| Voltage Output | 24 VDC RMS regulated |
| Max Total Output Load | 2.25 A |
| Supervisory Current | 5 mA |
| Delay Options | 0 / 10 / 20 / 30 seconds |
| Battery Capacity |
6.5 AH to 15 AH, up to 90 hours standby |
| Four-Wire Detector Power | 200 mA max |
| Non-Resettable Aux Power | 24 VDC regulated, 200 mA max |
| Cabinet Dimensions (HxWxD) | 16.0" x 14.5" x 5.375" |
| Standards Compliance | NFPA 12, 12A, 72, 2001; UL, ULC, FM, MEA, CSFM |
| Relay Contact Rating | 2 A @ 30 VDC; 0.5 A @ 30 VAC |
| End-of-Line Resistor | 4.7 kΩ, ½ W (P/N 71252) |
| Weight | 15 lbs |
Information About RP-1002
The RP-1002 is a flexible and robust control unit engineered to handle gaseous fire suppression agents in compliance with multiple NFPA standards, including NFPA 12 for CO₂, NFPA 12A for Halon 1301, and NFPA 2001 for clean agent systems. This panel supports both Style B and D configurations for initiating and abort circuits, and Style Y/Z for notification and releasing outputs. Its dual-hazard capability allows operators to control two separate suppression areas, or alternatively, configure one of the releasing circuits as a supervisory input.
Key Features:
- Dual-Hazard Releasing Support: Can control two separate suppression zones or one zone with supervisory input.
- Multi-Standard Compliance: Meets NFPA 72, NFPA 12, NFPA 12A, and NFPA 2001 standards for agent suppression.
- Power-Limited Circuitry: All input and output circuits (except municipal box output) are current-limited for safety.
- Delay Timer Configuration: Field-selectable activation delay settings of 0, 10, 20, or 30 seconds.
- Cross-Zone Activation Option: Provides enhanced protection by requiring confirmation from two initiating devices.
- Abort and Manual Release Inputs: Dedicated Style B/D circuits for local abort and manual discharge control.
- Multiple Notification Outputs: Two Style Y/Z notification appliance circuits for alarm and release tones.
- Modular Expansion Capability: Supports optional modules like 4XZM (relay), 4XTM (transmitter), 4XMM (meters), RZA-4X (remote annunciator), and 4XLM (LED interface).
- Audible and Visual Feedback: Distinct tones and indicators for one zone alarm, two zones alarm, and system release.
- Watchdog Timer and Event Recall: Supervises processor operation and stores last trouble event for diagnostics.
The RP-1002 offers code-compliant agent release functionality with modular expansion, making it ideal for high-risk environments requiring advanced fire suppression control.
