RRD-6NA-WH | Lutron Wireless Dimmer
- Regular price
- $742.00
- Sale price
- $742.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: RRD-6NA-WH
Description
The RRD‑6NA‑WH is a sleek, RF‑enabled Maestro dimmer designed for RadioRA 2 systems. It supports up to 600 W/VA loads at 120 VAC, including incandescent, halogen, ELV, MLV, CFL, and approved LED lighting.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Electrical Products
|
| Part Number | RRD-6NA-WH |
| Subcategory | Wall Switch |
| Input Volts | 120V |
| Family | RadioRA2 |
| Load Type | Halogen, Incandescent, LED, Magnetic Low Voltage (MLV) |
| Switch Type | 3-Way, Single Pole |
| Certifications | cUL |
| No. of Poles | 1 |
| Mounting |
Wall box/Wall Mount |
| Temperature Rating | 0° to 40°C |
| Color | Almond |
| Material | Metal/Plastic |
| Length | 0.31 in |
| Height | 4.69 in |
| Width | 2.94 in |
| Weight | 0.25 lbs |
Information About RRD-6NA-WH
The RRD-6NA-WH is a wireless in-wall dimmer developed by Lutron for use with RadioRA 2 lighting control systems. It supports a wide range of lighting loads up to 600 W/VA, including LED, CFL, incandescent, halogen, ELV, and MLV. With a neutral-wire adaptive design and intuitive tap/rocker control, it allows for flexible single-pole or multi-location installations. Integrated RF communication enables wireless operation, while built-in safety and fade features offer a refined user experience.
Key Features:
- Adaptive Load Control: Supports up to 600 W/VA of incandescent, halogen, MLV, ELV, LED, and CFL lighting.
- Neutral-Wire Operation: Requires a neutral wire for optimal dimming compatibility and performance.
- Wireless RF Integration: Communicates with RadioRA 2 systems for remote and scene-based control.
- Multi-Location Setup: Supports up to 9 companion dimmers or switches on the same circuit.
- Fade Functionality: Includes fade-on, fade-off, full-on, and delayed-off capabilities via intuitive tap/rocker interface.
- Front Accessible Service Switch (FASS): Allows safe bulb replacement without removing the dimmer.
- Status LED: Indicates dim level and provides night light functionality when lights are off.
- Environmental Rating: Operates in indoor environments from 32–104 °F (0–40 °C) and up to 90% non-condensing humidity.
- Compact Design: Fits standard wall boxes with a minimum depth of 2.25", ideal for retrofit or new construction.
The RRD-6NA-WH delivers reliable, wireless dimming control with sleek design and robust performance, making it ideal for upscale residential lighting installations.
Description
The RRD‑6NA‑WH is a sleek, RF‑enabled Maestro dimmer designed for RadioRA 2 systems. It supports up to 600 W/VA loads at 120 VAC, including incandescent, halogen, ELV, MLV, CFL, and approved LED lighting.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Electrical Products
|
| Part Number | RRD-6NA-WH |
| Subcategory | Wall Switch |
| Input Volts | 120V |
| Family | RadioRA2 |
| Load Type | Halogen, Incandescent, LED, Magnetic Low Voltage (MLV) |
| Switch Type | 3-Way, Single Pole |
| Certifications | cUL |
| No. of Poles | 1 |
| Mounting |
Wall box/Wall Mount |
| Temperature Rating | 0° to 40°C |
| Color | Almond |
| Material | Metal/Plastic |
| Length | 0.31 in |
| Height | 4.69 in |
| Width | 2.94 in |
| Weight | 0.25 lbs |
Information About RRD-6NA-WH
The RRD-6NA-WH is a wireless in-wall dimmer developed by Lutron for use with RadioRA 2 lighting control systems. It supports a wide range of lighting loads up to 600 W/VA, including LED, CFL, incandescent, halogen, ELV, and MLV. With a neutral-wire adaptive design and intuitive tap/rocker control, it allows for flexible single-pole or multi-location installations. Integrated RF communication enables wireless operation, while built-in safety and fade features offer a refined user experience.
Key Features:
- Adaptive Load Control: Supports up to 600 W/VA of incandescent, halogen, MLV, ELV, LED, and CFL lighting.
- Neutral-Wire Operation: Requires a neutral wire for optimal dimming compatibility and performance.
- Wireless RF Integration: Communicates with RadioRA 2 systems for remote and scene-based control.
- Multi-Location Setup: Supports up to 9 companion dimmers or switches on the same circuit.
- Fade Functionality: Includes fade-on, fade-off, full-on, and delayed-off capabilities via intuitive tap/rocker interface.
- Front Accessible Service Switch (FASS): Allows safe bulb replacement without removing the dimmer.
- Status LED: Indicates dim level and provides night light functionality when lights are off.
- Environmental Rating: Operates in indoor environments from 32–104 °F (0–40 °C) and up to 90% non-condensing humidity.
- Compact Design: Fits standard wall boxes with a minimum depth of 2.25", ideal for retrofit or new construction.
The RRD-6NA-WH delivers reliable, wireless dimming control with sleek design and robust performance, making it ideal for upscale residential lighting installations.
