S164B | Square D Micrologic LSIG Solid-State Trip Unit for Circuit Breakers
- Regular price
- $1,846.00
- Sale price
- $1,846.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: S164B
Description
The Square D S164B is a solid-state Micrologic trip unit designed to provide advanced protection functions for compatible low-voltage circuit breakers. It delivers precise long-time, short-time, instantaneous, and ground-fault (LSIG) protection to safeguard electrical distribution systems. This trip unit is used in industrial and commercial power systems requiring reliable and configurable overcurrent protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | S164B |
| Subcategory | Trip Units & Programmers |
| Product Family | Micrologic |
| Trip Unit Type | Solid-state |
| Protection Functions | LSIG (Long-Time, Short-Time, Instantaneous, Ground Fault) |
| Rated Voltage | Up to 600 V |
| Application | Circuit breaker protection and monitoring |
| Installation Type | Breaker-mounted |
| System Compatibility | Square D low-voltage circuit breakers |
| Usage Environment | Industrial and commercial electrical systems |
| Weight | 5.4 lb |
Information About S164B
The S164B is part of Square D’s Micrologic family of solid-state trip units engineered for enhanced circuit protection and monitoring. It is designed to integrate with compatible Square D molded case and power circuit breakers, enabling advanced protective functionality without altering breaker hardware. The unit uses electronic sensing technology to provide accurate response to overloads and fault conditions. Its configuration supports use in switchboards, panelboards, and motor control centers operating at voltages up to 600 V.
Key Features:
- Micrologic Trip Unit: Provides electronic protection and monitoring for circuit breakers.
- LSIG Protection Functions: Supports long-time, short-time, instantaneous, and ground-fault protection.
- Solid-State Technology: Delivers accurate and repeatable trip performance.
- 600 V System Compatibility: Designed for low-voltage distribution systems.
- Breaker Integration: Installs into compatible Square D circuit breakers.
- Industrial Application Ready: Suitable for switchgear, panelboards, and MCCs.
- Electronic Fault Detection: Enhances system safety and equipment protection.
The S164B delivers the reliability and precision required for advanced circuit protection in demanding electrical distribution environments.
