FCP34060 | Schneider Electric Three Pole Thermal Magnetic Molded Case Circuit Breaker 60A 480V
- Regular price
- $1,299.00
- Sale price
- $1,299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FCP34060
Description
The Schneider Electric FCP34060 is a three pole molded case circuit breaker designed to provide reliable protection for three-phase power distribution systems. It delivers thermal magnetic protection with long-time and instantaneous trip functions for controlled operation in industrial and commercial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Circuit Protection |
| Part Number | FCP34060 |
| Subcategory | Molded Case Circuit Breakers |
| Series | FCP |
| Frame Type | FCL |
| Amperage Rating | 60 A |
| Voltage Rating | 480 VAC |
| Number of Poles | 3 |
| Phase | 3 Phase |
| Interrupting Rating | 65 kAIC @ 480 V |
| Protection Type | Thermal Magnetic |
| Trip Functions | Long-Time and Instantaneous (LI) |
| Connection Type | Feed-Thru |
| Terminal Connection | Line and Load Side Lugs |
| Standards / Approvals | UL, CSA, NOM, IEC |
| Weight | 7 lbs |
Information About FCP34060
The FCP34060 is part of the Schneider Electric FCP Series, engineered for molded case circuit breaker applications requiring high interrupting capacity and dependable protection. This breaker supports three-phase electrical systems with a continuous current rating of 60 amps at 480 VAC. It incorporates a thermal magnetic trip unit that provides coordinated overload protection and instantaneous short-circuit response through long-time and instantaneous trip functions. The FCL frame construction and feed-thru connection design allow secure installation in panelboards and switchgear used in industrial power distribution environments.
Key Features
- Thermal Magnetic Protection Unit: Combines thermal overload sensing with instantaneous magnetic tripping to protect circuits from sustained overcurrent and short-circuit faults.
- High Interrupting Capacity: Rated at 65 kAIC at 480 V, enabling safe interruption of high fault currents in demanding electrical systems.
- Three Pole Configuration: Ensures balanced protection across all phases in three-phase power distribution networks.
- Feed-Thru Connection Design: Supports straight-through wiring using line and load side lugs for efficient panel layouts.
- FCL Frame Construction: Engineered for mechanical durability and consistent electrical performance under load and fault conditions.
- Wide Standards Compliance: Approved to UL, CSA, NOM, and IEC standards for use in regulated industrial environments.
The FCP34060 delivers the reliability and precision required for protecting three-phase power distribution circuits in commercial and industrial installations.
