Schneider Electric LC2D65G7 TeSys Deca Reversing Contactor 65A 120V AC for Motor Control
- Regular price
- $932.00
- Sale price
- $932.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: LC2D65G7
Description
The Schneider Electric LC2D65G7 is a reversing contactor designed for three-phase motor control in industrial power circuits. This unit combines two contactor assemblies with a mechanical interlock to reverse motor direction while maintaining controlled switching performance at 65 A AC-3 and up to 440 V. It is built for standard-duty automation panels where reliable forward and reverse motor operation is required.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Industrial Automation |
| Part Number | LC2D65G7 |
| Subcategory | Reversing Contactor |
| Product Line | TeSys Deca |
| Product Type | Reversing contactor |
| Poles Description | 3P |
| Power Pole Contact Composition | 3 NO |
| Auxiliary Contact Composition | 1 NO + 1 NC |
| Rated Operational Voltage | Power circuit up to 1000 V AC, 25...400 Hz |
| Rated Operational Current | 65 A at 440 V AC-3 / AC-3e |
| Control Circuit Voltage | 120 V AC, 60 Hz |
| Motor Power | 30 kW at 400 V |
| Utilisation Category | AC-2, AC-3, AC-4 |
| Rated Impulse Withstand Voltage | 6 kV |
| Mounting Support | Plate or DIN rail |
| Maximum Operating Rate | 3600 cycles/h at 60 °C |
| Mechanical Durability | 6,000,000 cycles |
| IP Protection | IP2X |
| Dimensions | 132 mm H x 165 mm W x 142 mm D |
| Weight | 2.4 kg |
Information About LC2D65G7
The LC2D65G7 is a TeSys Deca reversing contactor configured with 3 poles (3 NO), pre-wired power connections, and a mechanical interlock for reversing motor applications. It uses 120 V AC 60 Hz coils with a transient suppressor module and includes 1 NO + 1 NC built-in auxiliary contacts, with the NC mirror contact certified for monitoring functions. The device is intended for motor control duties in AC-2, AC-3, and AC-4 utilization categories, with screw clamp terminals for both power and control wiring and support for DIN rail or plate mounting. Schneider Electric lists it for operation in ambient temperatures up to 60 °C, with certifications including UL, CSA, CCC, DNV, BV, RINA, and UKCA-related approvals depending on market documentation.
Key Features:
- Reversing configuration: Integrates a reversing contactor assembly for forward and reverse motor control in one device.
- 65 A AC-3 rating: Rated for motor control applications at 65 A / 440 V in AC-3 and AC-3e duty.
- Mechanical interlock: Uses a built-in mechanical interlock to help prevent simultaneous opposite contactor closure.
- 120 V AC coil: Equipped with 120 V 60 Hz AC coils with transient suppression for control circuit operation.
- Built-in auxiliary contacts: Includes 1 NO + 1 NC auxiliary contacts, including a mirror-certified NC contact.
- Compact mounting format: Supports DIN rail mounting or screw fixing in a compact assembly for control panel installation.
- High operating endurance: Supports operating rates up to 3600 cycles per hour with mechanical durability rated at 6 million cycles.
- Industrial compliance: Manufactured to IEC/EN 60947 and UL/CSA-related standards for industrial switching applications.
The LC2D65G7 delivers the reliability and precision required for reversing motor starters and industrial three-phase motor direction control.
