SICK VL18L-3F324 PNP Retroreflective Laser Photoelectric Sensor
- Regular price
- $352.00
- Sale price
- $352.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VL18L-3F324
Description
The SICK VL18L-3F324 is a retroreflective laser photoelectric sensor for detecting objects that interrupt the light path between the sensor and a compatible reflector. It operates from a 10–30 V DC supply and provides a PNP light-switching output.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | SICK |
| Category | Sensors & Switches |
| Part Number | VL18L-3F324 |
| Subcategory | Photoelectric |
| Series | V18 Laser |
| Manufacturer Article Number | 6034330 |
| Detection Principle | Retroreflective, dual-lens system |
| Housing Configuration | Cylindrical M18 × 1; axial optical axis |
| Specified Sensing Range | 0.1–30 m with P250F reflector |
| Maximum Sensing Range | 0.1–35 m with P250F reflector |
| Light Source | Visible red laser, 650 nm |
| Laser Class | Class 1 |
| Supply Voltage | 10–30 V DC |
| Switching Output / Mode | PNP / light switching |
| Maximum Output Current | 100 mA |
| Switching Frequency | 800 Hz |
| Response Time | ≤0.625 ms with resistive load |
| Connection | M12 male connector, 4-pin |
| Enclosure Rating | IP67 |
| Weight | 0.13 lbs |
Information About VL18L-3F324
The VL18L-3F324 is part of SICK’s V18 Laser sensor family and carries article number 6034330. Its cylindrical M18 housing contains a dual-lens optical system with axial light emission. A Class 1 visible red laser produces a small light spot for detecting small objects. Sensitivity is adjusted through a teach-in button, while green and yellow LEDs indicate power and reception status.
Key Features:
- Retroreflective Detection: Detects interruptions in the beam returned by a compatible reflector.
- Class 1 Laser: Uses visible red laser light with a wavelength of 650 nm.
- PNP Output: Supplies a light-switching signal to compatible controller inputs.
- Sensing Range: Supports a specified range of 0.1–30 m with the P250F reflector.
- Switching Frequency: Provides an 800 Hz switching frequency.
- Teach-In Adjustment: Allows sensitivity configuration using a single pushbutton.
- Industrial Construction: Combines an M18 metal housing, IP67 protection, and an M12 connector.
The VL18L-3F324 delivers the reliability and precision required for object detection in compatible industrial automation equipment.
