SICK WLL190T-2P434 Fiber-Optic Amplifier, Dual PNP Outputs, IP66 Protection
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: WLL190T-2P434
Description
The SICK WLL190T-2P434 is a standalone fiber-optic photoelectric sensor amplifier designed for precise object detection in industrial automation and inspection applications. It provides PNP switching outputs, selectable light-on/dark-on operation, and adjustable response times, allowing it to detect small components and fast-moving objects when paired with a compatible fiber-optic cable. Its dual digital displays and configurable timing functions support convenient setup and monitoring in production environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | SICK |
| Category | Industrial Automation |
| Part Number | WLL190T-2P434 |
| Subcategory | Fiber-Optic Sensors |
| Manufacturer Part Number | 6032553 |
| Product Type | Stand-alone fiber-optic amplifier |
| Series | WLL190T-2 |
| Dimensions (W × H × D) | 10.5 × 34.8 × 76.5 mm |
| Sensing Technology | Fiber-optic photoelectric |
| Light Source | Visible red LED |
| Wavelength | 650 nm |
| Sensing Range — Proximity | 0–480 mm, depending on fiber and target |
| Sensing Range — Through-Beam | 0–2 m with specified fiber accessory; maximum range up to 4 m with specified configuration |
| Supply Voltage | 10–24 VDC |
| Supply Voltage Ripple | ≤10% |
| Current Consumption | 50 mA |
| Switching Outputs | 2 × PNP |
| Switching Mode | Light-on / dark-on, manually selectable |
| Programmable Delay Time | 0–9,999 ms |
| Connection Type | M8 male connector, 4-pin |
| Adjustment | Menu-controlled, single teach-in button, cable input |
| Display | LED status display and dual four-character digital displays |
| Housing Material | ABS/PC plastic |
| Enclosure Rating | IP66 with compatible fiber cable correctly attached and protection hood closed |
| Protection Class | III |
| Operating Temperature | −25 to +55 °C; limits vary with device grouping and output current |
| Storage Temperature | −40 to +70 °C |
| Weight | 25 g |
Information About WLL190T-2P434
The WLL190T-2P434 belongs to SICK’s WLL190T-2 series and uses a fiber-optic sensing arrangement in which the sensor amplifier works with a compatible fiber-optic head. It supports two switching outputs and offers adjustable sensitivity, teach-in operation, and selectable response-time settings to adapt detection behavior to different applications. The device includes a four-pin M8 male connector, a menu-controlled interface, and programmable delay functions for coordinating detection signals with machine sequences. Its IP66 enclosure rating and compact plastic housing support installation in industrial environments where dust and moisture protection are required.
Key Features:
-
Fiber-Optic Detection: Works with compatible fiber-optic cables to detect objects in confined or space-limited installations.
-
PNP Switching Outputs: Provides two switching outputs for connection to compatible PLCs and industrial controllers.
-
Selectable Light/Dark Switching: Supports configurable output logic to suit different detection requirements.
-
Adjustable Response Time: Offers selectable response times of 2 ms, 60 µs, and 250 µs for different operating speeds.
-
Dual Digital Displays: Displays set values and actual values using red and green indicators for convenient setup and monitoring.
-
Programmable Timer Functions: Supports switch-on delay, off delay, one-shot, or operation without delay.
-
M8 Four-Pin Connector: Provides a standardized connection for integration into control systems.
-
IP66 Protection: Helps protect the sensor against dust and water jets in suitable industrial installations.
The WLL190T-2P434 delivers the reliability and precision required for fiber-optic object detection, automated inspection, and high-speed production control.
