Siemens 1FK6042-6AF71-1AA0 SIMOTICS S Synchronous AC Servo Motor
- Regular price
- $3,085.00
- Sale price
- $3,085.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 1FK6042-6AF71-1AA0
Description
The Siemens 1FK6042-6AF71-1AA0 is a synchronous AC servo motor from the SIMOTICS S 1FK6 series, designed for precise motion control in industrial machinery and automated production equipment. It delivers a rated speed of 3,000 rpm and a maximum standstill torque of 3.2 Nm under the specified thermal conditions, with an incremental sin/cos encoder for position and speed feedback.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Industrial Automation |
| Part Number | 1FK6042-6AF71-1AA0 |
| Subcategory | Servo Motors |
| Product Family | SIMOTICS S 1FK6 |
| Motor Type | Synchronous AC Servo Motor |
| Number of Poles | 6 |
| Rated Speed | 3,000 rpm |
| Rated Torque | 2.6 Nm |
| Standstill Torque | 3.2 Nm at 100 K temperature rise |
| Rated Current | 2.4 A |
| Optimum Operating Power | 0.82 kW at 3,000 rpm |
| Encoder Type | Incremental sin/cos |
| Encoder Signal | 1 Vpp |
| Encoder Resolution | 2048 signal periods per revolution |
| Cooling Method | Natural cooling |
| Mounting Configuration | IM B5 (V1/V3 mounting options) |
| Shaft Type | Keyed shaft with feather key |
| Weight | 5.0 kg |
Information About 1FK6042-6AF71-1AA0
The 1FK6042-6AF71-1AA0 belongs to the Siemens 1FK6 family of synchronous servo motors developed for dynamic industrial drive applications. Its naturally cooled construction and IM B5 mounting arrangement support integration into compatible machine-drive assemblies. The motor includes an incremental sin/cos encoder with a 1 Vpp signal and 2048 signal periods per revolution, enabling feedback to compatible servo drives. Its keyed shaft, rotatable power and signal connectors, and IP64 protection rating support installation in suitable industrial environments; this version does not include a holding brake.
Key Features:
- Synchronous Servo Motor: Provides controlled rotary motion for industrial drive and automation systems.
- Rated Speed: Operates at a rated speed of 3,000 rpm under specified conditions.
- Standstill Torque: Provides up to 3.2 Nm standstill torque at a 100 K temperature rise.
- Incremental Encoder: Uses a sin/cos 1 Vpp encoder with 2048 signal periods per revolution for motion feedback.
- Natural Cooling: Uses a naturally cooled design without a separate cooling fan.
- Keyed Shaft: Features a shaft with feather key for secure mechanical coupling.
- Rotatable Connectors: Power and signal connectors can be rotated through 270° to accommodate installation requirements.
- IP64 Protection: Provides protection against dust ingress and water splashes from any direction under specified test conditions.
The Siemens 1FK6042-6AF71-1AA0 provides precise motion feedback and controlled rotational performance for industrial servo drive applications.
